The OneScreen OPS PC i7 LLF is a slot-in OPS computer module with an Intel Core i7-12850HX processor, 16 GB RAM, a 256 GB M.2 SATA SSD and Windows 11. It adds Wi-Fi 6, Bluetooth 5.2, six USB 3.2 ports and an RJ45 Ethernet port. Procure.ae, an authorised OneScreen reseller, supplies it across the UAE.
The OPS PC i7 LLF uses an Intel Core i7-12850HX processor with a speed range of 2.1 GHz to 4.9 GHz. It has 16 GB DDR4 memory with an additional slot, a 256 GB M.2 SATA SSD and a 2.5-inch SATA HDD or SSD bay. Intel UHD Graphics is the integrated graphics, and the unit runs Windows 11 with TPM 2.0 support. The 80-pin OPS connector takes a 12–19 V DC input and draws up to 60 W at maximum.
The module suits classrooms, meeting rooms and collaborative workspaces that need a Windows 11 computer built into the display setup. Six USB 3.2 ports, one USB-C port, a headset jack and an RJ45 Ethernet port cover peripherals and wired networking. The manufacturer lists FCC certification and an operating range of 0 to 45 °C. Procure.ae supplies and installs OPS modules across the UAE and offers free training and support.
| Key Features | Intel Core i7-12850HX, Windows 11, 16 GB DDR4 RAM, 256 GB M.2 SSD, TPM 2.0, Wi-Fi 6, Bluetooth 5.2, six USB 3.2 ports |
| Model | OPS PC i7 LLF |
| Type | OPS Slot-in PC |
| Graphics | Intel UHD Graphics |
| Operating System | Windows 11 |
| Processor | Intel Core i7-12850HX, 2.1 to 4.9 GHz |
| RAM | 16 GB DDR4 (additional slot) |
| Storage | 256 GB M.2 SATA SSD, plus 2.5-inch SATA HDD/SSD slot |
| Antenna | 2 x dual-band 2.4 GHz / 5 GHz |
| Bluetooth | Bluetooth 5.2 |
| Ethernet | 1 x RJ45 |
| Input Voltage | 12–19 V DC |
| Ports | USB 3.2 × 6, USB-C × 1, headset jack × 1 |
| Wi-Fi | Wi-Fi 6 |
| Power Consumption | 60 W (max) |
| Standby Power | 40 W |
| Dimensions | 195 x 180 x 30 mm (L x W x H) |
| Operating Humidity | 10% to 95% RH (at 40 °C) |
| Operating Temperature | 0 to 45 °C |
| Shipping Dimensions | 282 x 257 x 79 mm (L x W x H) |
| Shipping Weight | 1.4 kg |
| Weight | 1.2 kg |
| Certifications | FCC |
| Security Features | TPM 2.0 |
This sheet is compiled from the product data held on procure.ae. For fully accurate and up-to-date figures, always refer to the manufacturer’s own specification sheet or datasheet for this model.
Specifications are provided by the manufacturer and may change without notice.
