OneScreen OPS for Android – Android 13 OPS Computing Module
The OneScreen OPS for Android is a plug-in OPS computing module that adds Android 13 (EDLA certified) to an existing interactive flat panel. It has an octa-core CPU, 8 GB RAM, 128 GB storage, Wi-Fi 6 and Bluetooth 5.2, with HDMI 2.0 4K at 60 Hz in and out. This first-generation model is discontinued; Procure.ae can confirm UAE availability.
The OPS for Android uses an octa-core CPU with a Mali G57 MC5 GPU and a 4.8 TOPS NPU, 8 GB RAM and 128 GB storage. It provides Gigabit Ethernet, Wi-Fi 6 (2.4 GHz and 5 GHz) with hotspot capability, Bluetooth 5.2, 3 × USB 3.0 Type-A, 1 × USB Type-C, HDMI 2.0 in and out at 4K and 60 Hz, a 3.5 mm audio input and a 3.5 mm line output. Rated power is 35 W from a 12–19 V DC supply.
The module is intended to refresh OneScreen Touchscreen TL6 and earlier models, and the installation guide also covers the OneScreen TL7 and interactive flat panels from other manufacturers that have an OPS slot. It comes in small form (180 x 118 x 30 mm) and large form (192 x 180 x 42 mm) versions. Android 13 includes Google Play access, Play Protect, single sign-in for Google and Microsoft 365 applications and individual user profiles.
Key features
Specifications
| Compatibility | OneScreen Touchscreen TL6 and earlier, OneScreen TL7, OPS slots of other interactive panels |
| Key Features | Android 13 EDLA, octa-core CPU, 4.8 TOPS NPU, Wi-Fi 6, Bluetooth 5.2, HDMI 2.0 4K at 60 Hz in and out, small and large form |
| Model | OPS for Android |
| Type | Android OPS Module |
| Graphics | Mali G57 MC5 GPU, NPU 4.8 TOPS |
| Operating System | Android 13 (EDLA certified) |
| Processor | Octa-core CPU |
| RAM | 8 GB |
| Storage | 128 GB |
| Storage Conditions | -20 to 60 °C, 10% to 90% non-condensing |
| Audio In | 3.5 mm earphone audio in × 1 |
| Audio Out | 3.5 mm line out × 1 |
| Bluetooth | Bluetooth 5.2 |
| Ethernet | Gigabit Ethernet (1000 Mbps), RJ45 × 1 |
| HDMI Inputs | HDMI 2.0 In × 1 (4K at 60 Hz) |
| HDMI Outputs | HDMI 2.0 Out × 1 (4K at 60 Hz) |
| Input Voltage | 12–19 V DC (3 A to 1.84 A) |
| Ports | HDMI In × 1, HDMI Out × 1, USB 3.0 × 3, USB-C × 1, RJ45 × 1, 3.5 mm audio in × 1, 3.5 mm line out × 1 |
| USB Ports | USB 3.0 Type-A × 3, USB Type-C × 1 (host 3.0, data only) |
| Wi-Fi | Wi-Fi 6 (2.4 GHz and 5 GHz) with hotspot capability |
| Power Consumption | 35 W (rated) |
| Dimensions | 180 x 118 x 30 mm (small form); 192 x 180 x 42 mm (large form) |
| Form Factor | OPS, small form and large form |
| Operating Humidity | 10% to 90% RH, non-condensing |
| Operating Temperature | 0 to 40 °C |
| Shipping Dimensions | 245 x 186 x 57 mm (small form); 250 x 261 x 67 mm (large form) |
| Shipping Weight | 1.0 kg (small form); 1.47 kg (large form) |
| Weight | 0.75 kg (small form); 1.21 kg (large form) |
