OneScreen Hubware HL7 Education 98-inch 4K Interactive Flat Panel
The OneScreen Hubware HL7 Education 98-inch is an all-in-one interactive flat panel for classrooms. It combines a 98-inch 4K UHD display, 40-point infrared touch, a built-in Windows 11 OPS PC (Intel i7, 16 GB RAM, 256 GB SSD) and a 4K tracking camera with microphone. Procure.ae supplies it across the UAE.
The Hubware HL7 Education 98-inch has a 3840 x 2160 (4K UHD) LED-backlit display with 350 nits brightness, a 60 Hz refresh rate, a 178° viewing angle, 1.07 billion colours (10-bit) and a blue light filter. Zero-bonding infrared touch (Gen 2) supports 40 touch points with 1.5 mm accuracy and a response time under 7 ms. Two 16 W stereo speakers and level 7 Mohs anti-glare, anti-fingerprint glass complete the panel.
The panel runs Android 11 (quad-core ARM Cortex-A55 up to 1.8 GHz, 8 GB RAM, 64 GB storage) and also houses a Windows 11 OPS PC with Intel Iris Xe graphics and TPM 2.0, so teachers can use either environment. It works with learning management systems such as Blackboard, Canvas and Moodle, includes OneScreen Write, Share and Accounts software, and supports a flush wall mount on a VESA 400 x 200 pattern.
Screen Size
98 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
350 nits
Touch Technology
Infrared (zero-bonding, Gen 2)
- 98-inch 4K UHD Display
- 40-Point Infrared Touch
- Built-In Windows 11 OPS PC
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
98-inch 4K UHD Display
3840 x 2160 resolution at 60 Hz with 350 nits brightness and a 178° viewing angle.
02
40-Point Infrared Touch
Zero-bonding IR (Gen 2) with 1.5 mm accuracy and a response time under 7 ms.
03
Built-In Windows 11 OPS PC
Intel i7 processor, 16 GB RAM, 256 GB SSD, Intel Iris Xe graphics and TPM 2.0.
04
Android 11 System
Quad-core ARM Cortex-A55 up to 1.8 GHz with 8 GB RAM and 64 GB storage.
05
4K Tracking Camera
4K UHD camera with 110° field of view, up to 8x digital zoom, presenter tracking, auto-framing and an array microphone.
06
Stereo Speakers
Two 16 W speakers with stereo output.
07
Wireless and Wired Connectivity
Wi-Fi 6, Bluetooth 5.2, Gigabit Ethernet, HDMI inputs and a front USB-C port with 65 W power delivery.
08
Classroom Software
OneScreen Write annotation, OneScreen Share for up to 9 devices and interoperability with Blackboard, Canvas and Moodle.
Specifications
47 specificationsGeneral
CompatibilityBlackboard, Canvas, Moodle learning management systems
Key FeaturesBuilt-in Windows 11 OPS PC, 4K tracking camera, 40-point touch, Android 11, Wi-Fi 6, 2 × 16 W speakers, ambient light sensor, blue light filter
ModelHubware HL7 Education 98
TypeInteractive Flat Panel with Windows OPS PC
What's in the BoxHDMI cable, power cable, USB touch cable, USB-C cable, 2 stylus pens, display remote, camera remote, 2 Wi-Fi/Bluetooth antennas, wireless keyboard with touchpad
Display
Aspect Ratio16:9
BacklightLED
Blue Light FilterYes
Brightness350 nits
Camera4K UHD camera, 110° field of view, up to 8x digital zoom, electronic PTZ
Color Depth10-bit (1.07 billion colours)
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Screen Size98 inch
Touch Accuracy1.5 mm
Touch Points40-point multi-touch
Touch Response Time<7 ms
Touch TechnologyInfrared (zero-bonding, Gen 2)
Viewing Angle178°
Performance
GraphicsIntel Iris Xe Graphics (OPS PC)
Operating SystemAndroid 11 (panel); Windows 11 (OPS PC)
ProcessorQuad-core ARM Cortex-A55, up to 1.8 GHz (Android); Intel i7 (OPS PC)
RAM8 GB (Android); 16 GB (OPS PC)
Storage64 GB (Android); 256 GB SSD (OPS PC)
Audio
Audio Out3.5 mm audio out × 1
MicrophoneArray microphone
Speaker Output2 × 16 W stereo
Connectivity
BluetoothBluetooth 5.2
EthernetGigabit Ethernet, RJ-45 × 2
HDMI InputsHDMI In × 3 (1 front, 2 side)
HDMI OutputsHDMI Out × 1
Input Voltage100–240 V AC, 50/60 Hz
Serial PortRS-232 × 1
USB PortsUSB 3.0 × 4, USB 2.0 × 1, USB touch × 2
USB-C PortsUSB-C × 1 (65 W PD, front)
VGA InputVGA In × 1
Wi-FiWi-Fi 6 (2.4 GHz and 5 GHz)
Power
Power Consumption360 W (typical)
Physical
Dimensions2245 x 1323 x 92 mm
MountingFlush wall mount
Shipping Dimensions2406 x 1474 x 280 mm
Shipping Weight128.1 kg
Surface ProtectionLevel 7 Mohs anti-glare, anti-fingerprint glass
VESA Mount400 x 200 mm
Weight98.5 kg
Compliance
CertificationsFCC
Warranty3 years (standard)
Downloads
Manufacturer documents for the OneScreen Hubware HL7 Education 98-inch 4K Interactive Flat Panel — datasheets, manuals, drawings and certificates.
- Datasheet – Hubware HL7 Education – OneScreen Hubware for Education HL7 105 Spec Sheet
- Datasheet – Hubware HL7 Education – OneScreen Hubware for Education HL7 55 Spec Sheet
- Datasheet – Hubware HL7 Education – OneScreen Hubware for Education HL7 65 Spec Sheet
- Datasheet – Hubware HL7 Education – OneScreen Hubware for Education HL7 75 Spec Sheet
- Datasheet – Hubware HL7 Education – OneScreen Hubware for Education HL7 86 Spec Sheet
- Datasheet – Hubware HL7 Education – OneScreen Hubware for Education HL7 98 Spec Sheet
- User manual – Hubware HL7 Business – OneScreen-HL7-User-Manual
Questions
Can’t find your answer? Ask on WhatsApp
What screen quality does the OneScreen Hubware HL7 Education 98-inch offer?
It has a 98-inch 4K UHD (3840 x 2160) LED-backlit display with 350 nits brightness, a 60 Hz refresh rate, a 178° viewing angle, 10-bit colour (1.07 billion colours) and a blue light filter. The glass is level 7 Mohs anti-glare and anti-fingerprint.
How many touch points does the Hubware HL7 98-inch support?
It supports 40 simultaneous touch points using zero-bonding infrared touch (Gen 2). Touch accuracy is 1.5 mm and the response time is under 7 ms. Two stylus pens with an anti-bacterial coating are included in the box.
Does the Hubware HL7 Education 98-inch include a built-in computer?
Yes. It includes a Windows 11 OPS PC with an Intel i7 processor, 16 GB RAM, a 256 GB SSD, Intel Iris Xe graphics and TPM 2.0. The panel itself also runs Android 11 with 8 GB RAM and 64 GB storage, so both environments are available.
What camera and audio does the OneScreen Hubware HL7 98-inch have?
It has a OneScreen TrackCam with 4K UHD resolution, a 110° field of view and up to 8x digital zoom. Electronic pan, tilt and zoom support presenter tracking and auto-framing. An array microphone and two 16 W stereo speakers are built in.
How is the Hubware HL7 Education 98-inch mounted, and how heavy is it?
It uses a flush wall mount on a VESA 400 x 200 mm pattern. The panel measures about 2245 x 1323 x 92 mm and weighs 98.5 kg, so the wall and mount must be rated for the load. Procure.ae can arrange delivery and installation.
