Newline Lyra Pro Series Interactive Flat Panel – Lyra Pro

Name: Newline Lyra Pro Series Interactive Flat Panel – Lyra Pro
Brand: Newline
SKU: Lyra Pro
Availability: InStock

The Newline Lyra Pro is an interactive flat panel for business use, available in 55-inch to 98-inch sizes. It offers 4K UHD resolution, 20-point touch, Google EDLA certification and Android 14 with a 65 W powered USB-C port. Procure.ae supplies the Newline Lyra Pro in the UAE, with quotes, delivery and installation.

The Lyra Pro uses a direct LED backlit panel with 4K UHD resolution, 450 nits brightness, a 5000:1 contrast ratio and a 5 ms response time. Its Stellar touch system supports 20 touch points with ±1 mm accuracy and real palm rejection, and two passive pens are supplied. Certified zero bonding and 7H anti-glare glass with antimicrobial tempered surface support clear, precise writing on the screen.

The Lyra Pro runs Android 14 with Google EDLA certification and embedded Google Apps, and supports multiuser profiles. It has two HDMI 2.1 inputs with HDCP 2.2, a DisplayPort 1.2 input, three USB 3.2 touch ports, RS232, RJ45 Gigabit, an OPS slot and SDM-S sound system support. A camera and microphone array is an optional module. Dimensions, weight and VESA pattern vary by size, so check the size table before installation.

Resolution

3840 x 2160 (4K UHD)

Brightness

450 nits

Touch Technology

Stellar Touch Technology

Type

Interactive Flat Panel

Google EDLA certified
20-point touch
Zero bonding display

Price

On request · best price

WhatsApp Call

Download spec sheet (PDF) Manufacturer datasheet (PDF)

Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond

Manufacturer warrantyBacked by the brand

InstallationArranged on request

Key features

Google EDLA certified

Android 14 platform with Google EDLA certification and embedded Google Apps.

20-point touch

Stellar touch technology with 20 touch points, ±1 mm accuracy and palm rejection.

Zero bonding display

Certified zero bonding for precise writing on a 4K UHD panel.

65 W powered USB-C

Front USB-C port powered at 65 W.

HDMI 2.1 inputs

Two HDMI 2.1 inputs with HDCP 2.2 at 4K 60 Hz, plus DisplayPort 1.2 and HDMI out 2.0.

Optional camera and mic

A camera and microphone array is available as an optional module.

Wi-Fi 6 and Bluetooth 5.2

Integrated, replaceable wireless module with multiuser profiles.

Anti-glare glass

Anti-glare, anti-fingerprint glass with 7H hardness and antimicrobial tempered surface.

Specifications

27 specifications

General

Key FeaturesGoogle EDLA certified, 20-point touch, zero bonding, 4K UHD, 65 W powered USB-C, Android 14, Wi-Fi 6 and Bluetooth 5.2, SDM-S ready

ModelLyra Pro

TypeInteractive Flat Panel

Display

Aspect Ratio16:9

BacklightDirect LED with anti-blue light

Brightness450 nits

CameraOptional camera module

Color Depth1.07 billion colours

Color GamutWide colour gamut

Contrast Ratio5,000:1

Resolution3840 x 2160 (4K UHD)

Response Time5 ms

Touch Accuracy±1 mm

Touch Points20-point multi-touch

Touch TechnologyStellar Touch Technology

Viewing Angle178°

Performance

Operating SystemAndroid 14 (Google EDLA certified)

Audio

MicrophoneOptional microphone array module

Power Output180 W (power out connect)

Speaker Configuration2 x 20 W front-facing

Connectivity

BluetoothBluetooth 5.2

ExpansionOPS slot, SDM-S sound system ready

OPS Slot1 slot

PortsHDMI In 2.1 × 2, DisplayPort 1.2 × 1, USB 3.2 touch × 3, USB 3.2 Type-A × 2, HDMI Out 2.0 × 1, RS232 × 1, RJ45 Gigabit

Wi-FiWi-Fi 6

Power

Standby PowerLess than 0.5 W

Physical

Surface Protection7H hardness, anti-glare, anti-fingerprint, antimicrobial tempered glass

Downloads

Manufacturer documents for the Newline Lyra Pro Series Interactive Flat Panel – Lyra Pro — datasheets, manuals, drawings and certificates.

Questions

Can’t find your answer? Ask on WhatsApp

What sizes does the Newline Lyra Pro come in?

The Lyra Pro comes in 55-inch, 65-inch, 75-inch, 86-inch and 98-inch sizes, all with 4K UHD resolution. The model codes are TT-5523QA, TT-6523QA, TT-7523QA, TT-8623QA and TT-9823QA. Dimensions, weight, VESA and power consumption vary by size, so confirm the exact model code before ordering.

Does the Lyra Pro support 20-point touch?

Yes. The Lyra Pro uses Stellar touch technology with 20 touch points and ±1 mm accuracy. It supports real palm rejection, and two passive pens are supplied for writing and annotation.

Is the Lyra Pro compatible with Google Workspace?

Yes. The Lyra Pro is Google EDLA certified and runs Android 14 with embedded Google Apps. Multiuser profiles are supported, and the Wi-Fi 6 and Bluetooth 5.2 module is integrated in the display.

Can the Lyra Pro be wall mounted?

Yes. The VESA pattern is 400 x 400 mm for the 55-inch model, 600 x 400 mm for 65-inch, 800 x 400 mm for 75-inch and 86-inch, and 800 x 600 mm for 98-inch. The manufacturer notes that its measures are indicative, so check the final specification for the chosen size.

Can the Lyra Pro connect to a camera and microphone?

The camera and microphone array is an optional module for the Lyra Pro, so it is not included in every configuration. The display has a microphone input, a 3.5 mm audio line out, an OPS slot and SDM-S sound system support.
