NEC NP-PA903X 9000 Lumens XGA Resolution Installation Projector with 4K Support (Without Lens)

SKU: NP-PA903X

Actual Stock Can Be Confirmed After Placing the Order.

OVERVIEW NEC's PA903X is a 9000 lumen advanced professional installation model that appeases higher education and corporate users. With its multitude of digital inputs, connection to any computer or high definition device is possible. Enjoy design and installation flexibility with a complete line of... See More

EMAIL info@procure.ae

TELEPHONE (+971) 454 65041

WHATSAPP (+971) 454 65041

FREE SHIPPING All orders over AED1999/-

OVERVIEW

NEC's PA903X is a 9000 lumen advanced professional installation model that appeases higher education and corporate users. With its multitude of digital inputs, connection to any computer or high definition device is possible. Enjoy design and installation flexibility with a complete line of optional powered lenses (lens shift, focus and zoom), tilt-free and portrait installation capabilities along with built-in edge bledning and stacking. The HDBaseT input and seperate HDBaseT loop out provide single connections for uncompressed full HD digital video, audio, ethernet power and various control signals.

SPECIFICATIONS

Optical

Display Technology

0.76" LCD w/ MLA

Light Output(Lumens)

9000 normal

Resolution

Native	XGA 1024 x 768

Maximum	4K 4096 x 2160

Contrast Ratio (up to)

10,000:1 with auto iris

Lamp Type

420W AC

Lamp Life (up to)

3000 hours normal / 5000 hours eco

Screen Size (diagonal)

40 to 500 in. / 1.02 to 12.7m

Projection Distance

2.5 to 68.5 ft. / 0.74 to 20.9m

Projector Angle

10.3 to 10.8° tele / 13.7 to 14.5° wide

Lens

Zoom	Variable

Focus	Power

F number, fnumber	Variable

Shift	Mechanical -0.1 to +0.6 vertical, +/-0.3 horizontal

Keystone Correction

+/- 40° horizontal, +/- 30° vertical

Synchronization Range

Horizontal (Analog/Digital)	Analog: 15-100kHz, Digital: 15-153kHz

Vertical (Analog/Digital)	Analog: 48-120Hz, Digital: 24-120Hz

Supported Video Standards

NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM

SD/HD Video Signal Compatibility

480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 4K

PC Signal Compatibility

VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA, WQXGA

Macintosh Compatibility

Yes

Input/Output Terminals

RGB1(analog)	VGA 15-pin D-sub

RGB2(digital)	HDMI w/HDCP (V2.2)

RGB3(digital)	HDMI w/HDCP (V2.2)

RGB4(digital)	DisplayPort w/HDCP (V1.4)

RGB5(digital)	HDBaseT w/HDCP (V2.2)

Audio 1	Stereo Mini Jack

Monitor out	HDBaseT

Audio out	Stereo Mini Jack

External Control

RS-232, IR, HDBaseT, DDC/CI, USB

Sync Compatiblity

Separate Sync / Composite Sync / Sync on G

Electrical

Power Requirements	100-240V AC, 50/60 Hz

Input Current	6.2-3.1A

Power Consumption (Normal/ECO Mode/Standby/Standby Power Saving)	566W / 390W / 0.7W / 0.3W

Mechanical

Optional Lenses	NP11FL, NP12ZL, NP13ZL, NP14ZL, NP30ZL, NP40ZL, NP41ZL, NP42ZL

Installation Orientation	Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear

Dimensions (WxDxH)	19.8 x 16.2 x 6.6 in. / 503 x 411 x 168mm

Net Weight	22.5 lbs. / 10.2 kg

Fan Noise	39 dB normal / 33 dB eco

Regulations	USA UL60950-1: 2nd edition, FCC Part15 Subpart B(ANSI C63.4.2014), CAN/CSA C22.2 No.60950-1-07,2nd Edition,2014, ICES-003 Issue6(ANSI C63.4:2014)

Environmental

Operating Temperature	41-104°F / 5-40°C

Humidity	20-80% non-condensing

Storage	-14-122°F / -10-50°C

Limited Warranty

Registered owners receive a 3-year parts and labor warranty including InstaCare next business day exchange. One year on lamp.

Additional Features

4K Ready
Powered Lenses
Manual Keystone Correction
3D Stereo
Geometric Correction
10,000 hour Filter Life
Quick power on
ECO Mode Technology
DiCom Simulation
Edge Blending
Stacking
Virtual Remote
DisplayNote
NaViSet Administrator 2
Quick power-off
Picture-in-Picture
Advanced AccuBlend
AutoSense

Ships With

Remote control
Batteries
Power cord
Lens hole cap
User manual
Quick Start Guide
Product registration card
Lens anti-theft screw
