MAXHUB Smart Lectern 21.5-inch Touchscreen Podium – SL22MC

MAXHUB Smart Lectern 21.5-inch Touchscreen Podium – SL22MC

The MAXHUB SL22MC Smart Lectern is a floor-standing presentation podium with a 21.5-inch 1920 x 1080 capacitive touchscreen, a built-in Windows 10 IoT Enterprise PC module and electric height adjustment from 1.0 m to 1.2 m. It suits classrooms, lecture halls and boardrooms, and Procure.ae supplies it in the UAE.

The SL22MC combines a full-lamination display (450 nits with glass, 1,000:1 contrast, 178° viewing angle) with 10-point capacitive touch for fingers and an active capacitive pen, including palm rejection and ±1.5 mm accuracy. The integrated OPS72C PC module has an Intel Core i5-1240P processor, 16 GB RAM and 256 GB storage. Two gooseneck microphones pick up speech from 0 to 0.30 m, and dual-band Wi-Fi 802.11 a/b/g/n/ac supports wireless screen sharing within 10 m.

The column provides HDMI Out, XLR, 6.5 mm and 3.5 mm audio outputs, a Gigabit RJ45 port and USB 2.0 ports, so it can feed a projector, a display or a PA system. The manufacturer states it is compatible with MAXHUB All-in-one LED Wall and commercial displays. Two casters make it easy to move between rooms, and the manual advises fixing the base for long-term use. The datasheet lists a 3-year warranty.

Screen Size
21.5 inch
Resolution
1920 x 1080 (Full HD)
Brightness
450 nits (with glass, typical)
Touch Technology
Capacitive (finger and active capacitive pen)
Type
Smart Lectern (touchscreen podium with built-in PC)
Weight
29.9 kg

Key features

01
Electric height adjustment
The lectern lifts and lowers between 1.0 m and 1.2 m at 0.9 cm/s using the built-in motor.
02
Capacitive touchscreen
The 21.5-inch panel supports 10 touch points, finger and active capacitive pen input, and palm rejection.
03
Integrated PC module
An OPS72C module with Intel Core i5-1240P, 16 GB RAM and 256 GB storage runs Windows 10 IoT Enterprise.
04
Built-in microphones
Two gooseneck microphones are included, with a pickup distance of 0 to 0.30 m.
05
Wireless screen sharing
Dual-band Wi-Fi (2.4 GHz and 5 GHz, 802.11 a/b/g/n/ac) works within a range of 10 m.
06
Multiple audio outputs
Audio is available through XLR, 6.5 mm and two 3.5 mm outputs, plus an HDMI Out port.

Specifications

General
CompatibilityMAXHUB All-in-one LED Wall and commercial displays
Key Features21.5-inch capacitive touchscreen, electric height adjustment, built-in PC module, 2 gooseneck microphones, wireless screen sharing, XLR audio out
ModelSmart Lectern
TypeSmart Lectern (touchscreen podium with built-in PC)
What's in the BoxPower cord, HDMI cable, HDMI bridge cable, audio bridge cable, smart pen, 2 gooseneck microphones
Display
Aspect Ratio16:9
BacklightELED
Brightness450 nits (with glass, typical)
Color Gamut72% NTSC
Contrast Ratio1,000:1
Refresh Rate60 Hz
Resolution1920 x 1080 (Full HD)
Response Time14 ms
Screen Size21.5 inch
Touch Accuracy±1.5 mm
Touch Points10-point multi-touch
Touch TechnologyCapacitive (finger and active capacitive pen)
Viewing Angle178° (H/V)
Performance
Operating SystemWindows 10 IoT Enterprise
ProcessorIntel Core i5-1240P (1.7 GHz), OPS72C PC module
RAM16 GB
Storage256 GB
Audio
Audio OutXLR × 1, 6.5 mm × 1, 3.5 mm × 2
Microphone2 × gooseneck microphone, 0 to 0.30 m pickup
Connectivity
EthernetRJ45 × 1 (10/100/1000 Mbps)
HDMI OutputsHDMI Out × 1 (column base)
Input Voltage100–240 V AC, 50/60 Hz
USB PortsUSB 2.0 × 3 (2 on the side, 1 hidden for upgrade only)
Wi-Fi802.11 a/b/g/n/ac, 2.4 GHz / 5 GHz
Power
Power Consumption120 W (max)
Physical
Form FactorFloor-standing lectern on 2 casters
Height Range1.0 to 1.2 m (electric lift)
Operating Humidity10% to 90% RH
Operating Temperature0 to 40 °C
Weight29.9 kg
Compliance
Warranty3 years
QR code to MAXHUB Smart Lectern 21.5-inch Touchscreen Podium – SL22MC on procure.ae
Get our best price for this product
Scan to open it on procure.ae, or contact the Procure sales team:
☎ +971 4 546 5041  ·  WhatsApp  ·  ✉ info@procure.ae  ·  🔗 View product page

This sheet is compiled from the product data held on procure.ae. For fully accurate and up-to-date figures, always refer to the manufacturer’s own specification sheet or datasheet for this model.

Specifications are provided by the manufacturer and may change without notice.
