MAXHUBDigital SignageSKU ND75CMD
MAXHUB CMD Series 75-inch 4K Meeting Room Display – ND75CMD
The MAXHUB ND75CMD is a 75-inch 4K meeting room display from the CMD Series, built for video conferencing and screen sharing. It has a 5,000:1 typical contrast ratio, 300 nits typical brightness and Android 11, and it supports bring-your-own-meeting use from a laptop. Procure.ae supplies the ND75CMD across the UAE.
The ND75CMD uses a 3840 x 2160 VA panel with a 178-degree viewing angle, 72% NTSC colour gamut and a 6.5 ms response time. Its 8-core processor (4 x A73 and 4 x A53), 4 GB RAM and 32 GB storage run Android 11. Two 10 W bottom-gap speakers provide a 2.0 audio system, and the manufacturer rates the panel for at least 50,000 hours of life, with a 3-year warranty.
Meeting rooms can use the ND75CMD as a shared screen for laptops. Users can share wirelessly with MAXHUB Share, AirPlay, Miracast or Chromecast, or by Type-C cable, and up to 4 devices can share at once. The front Type-C port carries video, audio, touch, network and 65 W power. IT teams can manage the screen with MAXHUB Pivot, and RS232 or IP control suits room control systems. Compared with the 65-inch ND65CMD, it has a 5,000:1 typical contrast ratio against 6,000:1, and it draws 185 W typical power against 153 W.
Screen Size
75 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
300 nits (typical)
Type
Meeting Room Display
- 4K UHD screen
- High contrast
- Bring-your-own-meeting use
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
4K UHD screen
3840 x 2160 resolution on a 75-inch 16:9 VA panel, rated at 300 nits typical brightness.
02
High contrast
5,000:1 typical contrast ratio with 178-degree viewing angles.
03
Bring-your-own-meeting use
laptops running meeting software can use the display's screen and speakers.
04
Wireless screen sharing
MAXHUB Share, AirPlay, Miracast and Chromecast, with screen sharing for up to 4 devices at once.
05
65 W Type-C input
one front Type-C port carries video, audio, touch, network and 65 W power.
06
Remote management
MAXHUB Pivot lets IT managers monitor, control and update the display remotely.
07
Room control
RS232 and IP protocol control, with an RJ45 network port.
08
Android 11 platform
8-core CPU, 4 GB RAM, 32 GB storage, with Wi-Fi 6 and Bluetooth 5.2.
Specifications
40 specificationsGeneral
ApplicationMeeting rooms, boardrooms
Key FeaturesBYOM meeting support, screen sharing for up to 4 devices, MAXHUB Share, MAXHUB Pivot remote management, RS232/IP control, HDMI CEC, built-in media player, one-key black screen
ModelND75CMD
TypeMeeting Room Display
Display
Aspect Ratio16:9
BacklightDLED
Brightness300 nits (typical)
Color Depth1.07 billion colours (8-bit + FRC)
Color Gamut72% NTSC (typical)
Contrast Ratio5,000:1 (typical)
Panel TechnologyVA
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Response Time6.5 ms
Screen Size75 inch
Viewing Angle178°
Performance
GraphicsMali G52MP8
Operating SystemAndroid 11
ProcessorOcta-core (4 x A73 + 4 x A53)
RAM4 GB
Storage32 GB
Storage Conditions-20 to 60 °C, 10% to 90% RH
Audio
Speaker Configuration2.0
Speaker Output2 × 10 W
Connectivity
BluetoothBluetooth 5.2
EthernetRJ45 × 1
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In × 2, USB 2.0 × 1, USB 3.0 × 2 (front), USB-C × 1 (65 W PD, front), Touch 2.0 × 1, RS232 × 1, RJ45 × 1, Audio In × 1, Audio Out × 1
Serial PortRS232 × 1
Wi-FiWi-Fi 6, 802.11ac/b/g/n/a/ax, 2.4 GHz and 5 GHz
Power
Power Consumption185 W (typical), 295 W (maximum)
Standby Power≤ 0.5 W
Physical
Dimensions1669 x 968.1 x 75.9 mm
Duty Cycle7 x 16 hours per day
Operating Humidity10% to 90% RH
Operating Temperature0 to 40 °C
VESA Mount400 x 300 mm
Weight25 kg
Compliance
CertificationsEnergy Star
Warranty3 years
Downloads
Manufacturer documents for the MAXHUB CMD Series 75-inch 4K Meeting Room Display – ND75CMD — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Can the ND75CMD be used for video conferencing?
Yes. Laptops running meeting software can use the display's screen and speakers through bring-your-own-meeting use. The front Type-C port carries video, audio, touch and network signals with 65 W power, so one cable can connect a laptop. Meeting software support depends on the laptop platform.
Does the ND75CMD work with room control systems?
Yes, it supports RS232 and IP protocol control, with an RS232 port and an RJ45 network port. The manufacturer's specifications do not name specific control platforms for this model, so Procure.ae can confirm integration with your system before you order.
What wall mount does the ND75CMD use?
The ND75CMD uses a 400 x 300 mm VESA pattern with M6 x 30 mm wall-hanging screws. Its net weight is 25 kg, so the wall and bracket should be planned for that load. Procure.ae can advise on mounting and installation when you request a quote.
How does the ND75CMD differ from the ND65CMD?
The ND75CMD is 75 inches, with 5,000:1 typical contrast, 185 W typical power use and a 25 kg net weight. The ND65CMD is 65 inches, with 6,000:1 typical contrast, 153 W typical power use and a 17 kg net weight. Both share the same ports, Android 11 platform and 4K resolution.
Does the ND75CMD come with a warranty?
Yes. The manufacturer lists a 3-year display warranty, and its brochure describes a three-year swap service. Procure.ae can confirm the warranty terms that apply to your UAE order when you request a quote.
Can I buy the ND75CMD in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
