MAXHUB 86 inch U4 Series Interactive Display – Model U8640MAXHUB

MAXHUB 86 inch U4 Series Interactive Display – Model U8640

The MAXHUB 86 inch U4 Series Interactive Display – Model U8640 is a interactive flat panel available in the UAE from Procure.ae.

The MAXHUB 86 inch U4 Series Interactive Display – Model U8640 is the ultimate solution for modern meeting rooms, educational environments, and collaborative workspaces. Featuring an impressive 86 inch 4K ultra HD touchscreen , this interactive display delivers crystal-clear visuals and seamless touch responsiveness for an engaging user experience. With advanced multi-touch technology , the MAXHUB U8640 supports up to 20-point touch, making group collaboration effortless. The integrated wireless screen sharing allows easy content sharing from any device, while the built-in Android operating.

It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.

Screen Size
86 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
500 nits
Touch Technology
Infrared
  • 86 Inch 4K UHD Display
  • 20-Point Multi-Touch
  • Integrated Camera & Microphone
Price
On request · best price
1
Download spec sheet (PDF) Manufacturer datasheet (PDF)
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request

Key features

01
86 Inch 4K UHD Display
Exceptional ultra-high-definition visuals for immersive presentations.
02
20-Point Multi-Touch
Supports multiple users for simultaneous collaboration and interactivity.
03
Integrated Camera & Microphone
Crystal-clear video and audio for seamless video conferencing.
04
Wireless Screen Sharing
Effortlessly share content from laptops, tablets, or smartphones.
05
Built-in Android OS
User-friendly interface with access to a range of apps and tools.
06
Anti-Glare Tempered Glass
Ensures clear viewing from any angle, even in brightly lit rooms.
07
All-in-One Design
Sleek, modern appearance with integrated speakers and ports.
08
Multiple Connectivity Options
Includes HDMI, USB, and LAN ports for versatile use.

Specifications

45 specifications
General
Key FeaturesPalm rejection, Pen and touch differentiation
What's in the BoxSmart Pen: SP30B, Sensor Box: WL10C, WL20, Mobile Stand: ST33M, ST23B, EST09
Display
Aspect Ratio16:9
BacklightDirect LED
Blue Light FilterYes
Brightness500 nits
Camera50 MP
Color Depth10-bit (1.07 billion colours)
Color Gamut98% sRGB
Contrast Ratio1,200:1
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size86 inch
Touch Accuracy±0.5 mm
Touch Points50-point multi-touch
Touch TechnologyInfrared
Viewing Angle178° (H) / 178° (V)
Performance
GraphicsArm Mali-G610 MP4
Operating SystemAndroid 15
ProcessorARM 4x Cortex-A76 + 4x Cortex-A55, 2.4 GHz
RAM16 GB
Storage256 GB
Audio
Audio InAudio in × 1
Audio OutAudio out × 1
DisplayPortDisplayPort In × 1
Microphone8-mic array, 12 m pickup range
Pickup Range12 m
Speaker Output2 × 8 W + 2 × 18 W (output); 2 × 12 W + 2 × 25 W (maximum)
Speaker TypeBuilt-in
Connectivity
BluetoothBluetooth 5.2
EthernetRJ45 In × 1, RJ45 Out × 1
HDMI InputsHDMI In × 4
HDMI OutputsHDMI Out × 1
Input Voltage100–240 V AC, 50/60 Hz
OPS SlotYes (module slot)
SD Card SlotmicroSD card slot × 1
Serial PortRS-232 × 1
Touch USB PortsTouch USB × 2
USB PortsUSB 2.0 × 1, USB 3.0 × 4
USB-C PortsUSB-C × 2
Wi-FiWi-Fi 6 (802.11ax), 2.4/5 GHz
Power
Power Consumption100 W
Standby Power0.5 W
Physical
Surface ProtectionAnti-glare (etched), 25% haze

Questions

Can’t find your answer? Ask on WhatsApp

What is the MAXHUB interactive flat panel used for?
The MAXHUB 86 inch U4 Series Interactive Display – Model U8640 is the ultimate solution for modern meeting rooms, educational environments, and collaborative workspaces. Featuring an impressive 86 inch 4K ultra HD touchscreen , this interactive display delivers crystal-clear visuals and seamless.
Does it include installation and warranty?
Procure.ae can arrange installation and provides manufacturer-backed warranty support. Contact us for the full warranty details applicable to this model.
Does this interactive panel support multi-touch and on-screen writing?
Yes — it uses Infrared touch technology, so multiple users can write and interact at the same time.
Can I run apps on it without connecting a PC?
Yes — it runs Android 15, so you can open apps, whiteboard, and browse without a separate computer.
