MarvelDigital SignageSKU MWE663 High Brightness Stretched Bar LCD
Marvel High Brightness Stretched Bar LCD Display – MWE663
Marvel MWE663 is a high-brightness stretched bar LCD display for long, narrow digital signage. It delivers 400 nits, a 1366 x 196 resolution and an Android 4.2.2 player with HDMI output. Procure.ae supplies the Marvel MWE663 in the UAE for supermarket and retail signage projects.
The Marvel MWE663 is a stretched bar LCD display with a 16:2.3 display ratio, built to show long, narrow digital signage messages. It uses an LED backlight rated at 400 nits and has a 1366 x 196 resolution, a 60 Hz refresh rate and a 1 ms response time. An Android 4.2.2 player runs on a dual-core Cortex-A7 CPU with 1 GB DDR3 memory and 8 GB NAND flash storage. Viewing angles are 85° left and right and 80° up and down. The manufacturer's specifications list a backlight life of 50,000 hours.
The MWE663 suits supermarket and retail signage where a long, narrow screen fits the space above or beside a shelf or entrance. Content can be loaded from USB or an SD card, and the 100M LAN port provides a wired network connection. The wall mount bracket, adapter and power cord are supplied with the unit. The manufacturer's data lists both indoor and outdoor application, so confirm the installation environment with Procure.ae before fixing the unit.
Resolution
1366 x 196
Brightness
400 nits
Type
Stretched Bar LCD Display
- Stretched Bar Format
- High Brightness Panel
- Android Player
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Stretched Bar Format
A 16:2.3 display ratio and a 410.5 x 61 mm display area suit long, narrow signage.
02
High Brightness Panel
The LED-backlit panel is rated at 400 nits brightness.
03
Android Player
Runs Android 4.2.2 on a dual-core Cortex-A7 CPU with a Mali-400MP GPU.
04
Connectivity Ports
Includes HDMI output, two USB 2.0 ports, an SD card slot and a 100M LAN port.
05
Media Formats
Plays AVI, MP4 and MPEG video, JPG, BMP, PNG and GIF pictures, and MP3 or WMA audio.
06
Wide Viewing Angle
Viewing angles of 85° left and right and 80° up and down.
07
Wall Mount Supplied
Adapter, power cord and wall mount bracket are listed in the package contents.
Specifications
29 specificationsGeneral
Key FeaturesStretched bar format, 400 nits, LED backlight, Android 4.2.2, HDMI output, SD card slot, wall mount
ModelMWE663 High Brightness Stretched Bar LCD
TypeStretched Bar LCD Display
What's in the BoxAdapter, power cord, wall mount bracket
Display
Aspect Ratio16:2.3
BacklightLED
Brightness400 nits
Color Depth16.7 million colours
Contrast Ratio1,000:1
Display TypeLCD
Lamp Life50,000 hours
Refresh Rate60 Hz
Resolution1366 x 196
Response Time1 ms
Viewing AngleR/L 85°, U/D 80°
Performance
Operating SystemAndroid 4.2.2
RAM1 GB DDR3
Storage8 GB NAND flash
Audio
AudioStereo
Connectivity
Input Voltage100–240 V AC, 50/60 Hz
PortsUSB 2.0 × 2, LAN × 1, SD card slot × 1, HDMI out × 1, 100M LAN × 1
Power
Power Consumption15 W
Physical
ColorBlack (optional)
Dimensions432.5 x 83 x 30.5 mm
MountingWall mount bracket included
Operating Humidity20% to 85% RH
Operating Temperature0 to 50 °C
Compliance
CertificationsCE / FCC / RoHS / ISO
IP RatingIP65
Questions
Can’t find your answer? Ask on WhatsApp
Is the Marvel MWE663 a stretched bar display?
Yes. The MWE663 is a stretched bar LCD with a 16:2.3 display ratio and a 410.5 x 61 mm display area. It is designed for long, narrow digital signage where a standard landscape screen does not fit the space.
What screen sizes does the MWE663 come in?
The manufacturer's specifications list 16.3-inch, 18.9-inch, 28.8-inch and 34.9-inch screen sizes for the MWE663 range, with an outline size of 432.5 x 83 x 30.5 mm. Confirm the exact size you need with Procure.ae before ordering, because the range lists several sizes.
Does the MWE663 run on Android?
Yes. It runs Android 4.2.2 on a dual-core Cortex-A7 CPU with a Mali-400MP GPU, 1 GB DDR3 memory and 8 GB NAND flash storage. Content can be loaded from a USB device or an SD card, and the unit provides an HDMI output for a connected source.
Can the MWE663 be wall mounted?
Yes. The manufacturer's specifications list a wall mount bracket in the package, together with an adapter and a power cord. Confirm the wall fixing, cable routing and power point position with Procure.ae for your site before installation.
Which video and picture formats does it support?
It plays AVI, MP4 and MPEG video and displays JPG, BMP, PNG and GIF pictures. It also plays MP3 and WMA audio files, and the manufacturer lists stereo sound output.
Can I buy the MWE663 in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
