OVERVIEW

DESIGNED FOR BUSY OFFICES

Phone calls in active work environments can be difficult. The H820e Headset is designed for these situations. The headset automatically pairs with any H820e dock – ideal for hot desking. An LED lets others know you’re on the phone, while a visual indicator tells you when you have an incoming call

READY FOR BUSINESS

The H820e Headset is certified for use with leading conference software applications such as Skype for Business and Cisco® Jabber™. H820e is recommended for heavy-duty business users in open workspaces, offices, or home offices. Choose H820e Mono or H820e Dual for one or two speakers.

SPECIFICATIONS

DIMENSIONS
HEADSET:
Height x Width x Depth: 6.5 in (165 mm) x 6.8 in (174 mm) x 2.0 in (50 mm)
Weight: 4.5 oz (128 g) (Dual)
Weight: 3.1 oz (88 g) (Mono)
BASE:
Height x Width x Depth: 5 in (128 mm) x 2.8 in (73 mm) x 3.3 in (82 mm)
Weight: 1.8 lb (475 g)

SYSTEM REQUIREMENTS
COMPATIBLE WITH
WindowsVista®, Windows® 7 or Windows 8 (32-bit or 64-bit), Windows 10
Mac® OS X® 10.7 or higher
Linux®
Available USB port
AC power

OTHER ATTRIBUTES
In-call LED red light indicator on backside of boom
Mute LED red-light indicator on boom

TECHNICAL SPECIFICATIONS
MICROPHONE (TX)
Type: Bi-directional ECM
Frequency response: 100 Hz - 7 KHZ
Sensitivity: -45 dB +/- 3 dB
Distortion: <10% @ 1kHz, 10dBPa (MRP) input
Operating voltage: 1.4 - 5.0V DC
SPEAKERS (RX)
Frequency response: 150 Hz - 7kHz (ITU-T TIA920)
Sensitivity: 103dB ±3 dB at 1KHz, Input 1mW/ Type 4153 artificial ear
Distortion: < 4% @ 1kHz, 0dBm0, 1kHz
BATTERY
Type: Lithium ion
Weight: 9 g
Capacity: 430mAh

PACKAGE CONTENTS
Headset Charging stand
AC power adapter
USB cable
Quick Start guide and warranty card

WARRANTY INFORMATION
2-Year Limited Hardware Warranty
