LGMeeting Room SolutionsSKU KT-T320
LG KT-T Series 32-inch Infrared Touch Overlay Kit – KT-T320
The LG KT-T320 is a discontinued 32-inch infrared touch overlay kit that adds touch input to a compatible display. It offers 10-point multi-touch, 1 mm accuracy and a USB 2.0 connection for Windows, Mac, Android and Linux. Procure.ae supplies LG accessories in the UAE and can confirm whether this kit is currently available.
The KT-T320 uses infrared touch sensing with 1 mm accuracy and supports up to 10 touch points at a touch resolution of 1428 x 803. The manufacturer lists Windows 7, Windows 8, Mac OS X 10.7 or later, Android and Linux kernel 3.9 or later as supported operating systems. It connects over USB 2.0 and draws power from USB. The kit is listed for a 32-inch screen in landscape and portrait orientation, and is also listed as KT-T320.AL.
Screen Size
32 inch
Touch Technology
Infrared
Type
Touch Overlay Kit
Weight
4.1 kg
- Infrared touch
- Multi-touch
- USB connection
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Infrared touch
Infrared touch type with 1 mm accuracy.
02
Multi-touch
Up to 10 touch points at a 1428 x 803 touch resolution.
03
USB connection
USB 2.0 interface, powered from USB.
04
Broad OS support
Windows 7, Windows 8, Mac OS X 10.7 or later, Android and Linux kernel 3.9 or later.
05
Landscape and portrait
Supports landscape and portrait orientation with a 27.0 mm bezel width.
Specifications
17 specificationsGeneral
Key FeaturesInfrared touch, 1 mm accuracy, 10-point multi-touch, USB 2.0, no interactive whiteboard software included
ModelKT-T320
TypeTouch Overlay Kit
What's in the BoxTouch overlay, manual, installation accessories
Display
Bezel Size27.0 mm
OrientationLandscape and portrait
Screen Size32 inch
Touch Accuracy1 mm
Touch Points10-point multi-touch
Touch Resolution1428 x 803
Touch TechnologyInfrared
Performance
Operating SystemWindows 7, Windows 8, Mac OS X 10.7 or later, Android, Linux (kernel 3.9 or later)
Connectivity
PortsUSB 2.0 × 1
Power
Power SourceUSB
Physical
Operating Humidity10% to 80% RH
Operating Temperature0 to 40 °C
Weight4.1 kg
Downloads
Manufacturer documents for the LG KT-T Series 32-inch Infrared Touch Overlay Kit – KT-T320 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Which screen size does the KT-T320 cover?
The manufacturer lists a 32-inch screen size with a 1428 x 803 touch resolution and a 27.0 mm bezel width. Check the target display's active area and bezel against these figures before ordering.
Does it work with Windows, Mac and Android?
Yes. The manufacturer lists Windows 7, Windows 8, Mac OS X 10.7 or later, Android and Linux kernel 3.9 or later. It connects over USB 2.0 and supports up to 10 touch points with 1 mm accuracy.
Does the KT-T320 need extra software?
The manufacturer lists no interactive whiteboard software for the KT-T320, so the overlay is supplied without an IWB application. Check the setup requirements for your operating system before deployment, and confirm driver support with your IT team.
