LG High-Brightness Open-Frame 55-inch Digital Signage Display – 55XF3E

The LG 55XF3E is a 55-inch open-frame digital signage display with 3,000 nits typical brightness and direct sunlight support. Its 1920 x 1080 IPS panel and 600 x 400 mm VESA interface suit bright indoor and window-side sites. Procure.ae supplies the LG 55XF3E across the UAE.

The 55XF3E is rated at 3,000 nits typical and 2,400 nits minimum brightness, with 1,300:1 contrast and 500,000:1 dynamic contrast. Its 1920 x 1080 IPS panel runs 24/7 at 60 Hz with 8 ms grey-to-grey response and 178° viewing angles. The display has an auto brightness sensor, a humidity sensor and a built-in fan. It operates at 0 to 50 °C without direct sunlight and 0 to 40 °C in direct sunlight, and runs webOS 3.0 with SuperSign CMS and SuperSign Control+.

The 55XF3E suits open-frame installations where the panel is fitted into a custom enclosure or bracket. Its VESA interface is 600 x 400 mm, and monitor dimensions are 1235.5 x 709.4 x 106.8 mm. Inputs include two HDMI, DVI-D, DisplayPort in and out, audio in, external speaker out, RS232C, RJ45 LAN and IR input. Tile mode setting and backlight sync are listed for multi-panel use. The model is also listed under the codes 55XF3E-B.AMA and 55XF3E-B.AMN.

Screen Size

55 inch

Resolution

1920 x 1080 (Full HD)

Brightness

3,000 nits (typical), 2,400 nits (minimum)

Type

Open-Frame Signage Display

Weight

26.5 kg (head)

Key features

Direct sunlight support

Listed for direct sunlight, with 40 °C operation in direct sunlight.

High brightness

3,000 nits typical and 2,400 nits minimum.

Full HD IPS panel

1920 x 1080 with 178° viewing angles.

Environmental sensors

Auto brightness and humidity sensors with a built-in fan.

Multiple inputs

Two HDMI, DVI-D, DisplayPort in and out, and audio in.

Tile mode

Tile mode setting and backlight sync for multi-panel arrays.

Signage software

SuperSign CMS and SuperSign Control+ listed.

VESA mounting

600 x 400 mm interface.

Specifications

General
Key Features	Direct sunlight rated, Auto brightness sensor, Humidity sensor, Portrait/landscape, Tile mode, SuperSign CMS, Backlight sync, Beacon
Model	55XF3E
Type	Open-Frame Signage Display

Display
Aspect Ratio	16:9
Bezel Size	12 mm (top), 9.9 mm (sides), 12 mm (bottom)
Brightness	3,000 nits (typical), 2,400 nits (minimum)
Color Depth	16.7 million colours
Color Gamut	NTSC 67%
Contrast Ratio	1,300:1 (dynamic 500,000:1)
Panel Technology	IPS
Refresh Rate	60 Hz
Resolution	1920 x 1080 (Full HD)
Response Time	8 ms (G to G)
Screen Size	55 inch
Viewing Angle	178° x 178°

Performance
Operating System	webOS 3.0

Connectivity
Input Voltage	100–240 V AC, 50/60 Hz
Ports	HDMI In × 2, DP In × 1, DP Out × 1, DVI-D In × 1, Audio In × 1, External Speaker Out × 1, RS232C In/Out, RJ45 LAN In, IR In, USB 2.0 Type A × 1

Power
Power Consumption	0.5 W (standby)

Physical
Dimensions	1235.5 x 709.4 x 106.8 mm
Duty Cycle	24/7
Operating Humidity	10% to 80% RH
Operating Temperature	0 to 50 °C (40 °C in direct sunlight)
VESA Mount	600 x 400 mm
Weight	26.5 kg (head)

Compliance
Certifications	IEC 60950-1, EN 60950-1, UL 60950-1, FCC Class A, CE, KC
