LG EV5E Series 65-inch 4K UHD OLED Video Wall Display – 65EV5E-2

LG EV5E Series 65-inch 4K UHD OLED Video Wall Display – 65EV5E-2

The LG 65EV5E-2 is a 65-inch 4K UHD OLED video wall display from the LG EV5E Series, for video walls and digital signage in commercial spaces. It has a 3,840 x 2,160 resolution and a 1.2 mm even bezel, and it is offered in 1x2 and 1x3 sets. Procure.ae can confirm availability of the LG 65EV5E-2 across the UAE.

The 65EV5E-2 uses a 65-inch OLED panel at 3,840 x 2,160 (UHD) resolution. Brightness is rated at 400 nits at APL 25% and 150 nits at APL 100%. Inputs are HDMI, DisplayPort and two USB 2.0 ports, with DisplayPort and audio outputs. Its even bezel is 1.2 mm, and the manufacturer lists a 6.7 mm on-bezel seam. The 1x2 set measures 1,634.6 x 1,446.7 x 7.9 mm and weighs 29.4 kg, while the 1x3 set measures 2,445.4 mm wide and weighs 44.5 kg. Operating temperature is 0 to 40 °C.

The 65EV5E-2 is supplied with fixer screws, anchor bolts, polyester tapes and panel jigs for wall installation, and the signage box connects to the panel with FFC cables. External control is available through RS232C In/Out, RJ45 LAN In/Out and IR In. Content is managed with SuperSign CMS, and units can be monitored with SuperSign Control+ or SuperSign Control. An external media player can be attached, but the manufacturer lists the model as not OPS compatible.

Screen Size
65 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
150 nits (APL 100%) / 400 nits (APL 25%)
Type
OLED Video Wall Display
Weight
29.4 kg (1x2 set)

Key features

01
OLED UHD panel
65-inch OLED panel with 3,840 x 2,160 native resolution.
02
Even bezel
1.2 mm even bezel with a 6.7 mm on-bezel seam for tiled walls.
03
1x2 and 1x3 sets
two configurations, with the 1x3 set measuring 2,445.4 mm wide.
04
Brightness rating
400 nits at APL 25% and 150 nits at APL 100%.
05
Inputs and outputs
HDMI, DisplayPort and two USB 2.0 inputs, with DisplayPort and audio outputs.
06
Network control
RS232C In/Out, RJ45 LAN In/Out and IR In.
07
SuperSign software
SuperSign CMS for content, SuperSign Control+ or Control for monitoring.
08
Wall installation kit
fixer screws, anchor bolts, polyester tapes and panel jigs included.

Specifications

General
ApplicationVideo walls, digital signage
Key FeaturesOLED panel, 4K UHD 3840 x 2160, 1.2 mm even bezel, 1x2 and 1x3 sets, SuperSign CMS, SuperSign Control+, external media player attachable
Model65EV5E-2
TypeOLED Video Wall Display
What's in the BoxRemote controller, power cord, IR receiver, RS232 cable, DP cable, LAN cable, LC cable, fixer screws, anchor bolts, polyester tapes, panel jigs
Display
Bezel Size1.2 mm (even); off-bezel 9.1 mm (T/B), 8.7 mm (L), 11.6 mm (R)
Brightness150 nits (APL 100%) / 400 nits (APL 25%)
Panel TechnologyOLED
Resolution3840 x 2160 (4K UHD)
Screen Size65 inch
Connectivity
ConnectivityRS232C In/Out, RJ45 LAN In/Out, IR In
Input Voltage100–240 V AC, 50/60 Hz
PortsHDMI In, DisplayPort In, USB 2.0 × 2, DisplayPort Out, Audio Out, RS232C In/Out, RJ45 LAN In/Out, IR In
Physical
Dimensions1634.6 x 1446.7 x 7.9 mm (1x2 set)
Operating Humidity10% to 80% RH
Operating Temperature0 to 40 °C
Shipping Weight69.6 kg (1x2 set, packed on pallet)
Weight29.4 kg (1x2 set)
Compliance
CertificationsIEC 60950-1, EN 60950-1, UL 60950-1, FCC Class A, CE, KC
