Jabra PanaCast 55 VBS Bar Only Video Bar – 8930-231

The Jabra PanaCast 55 VBS Bar Only (model 8930-231) is a 180-degree video conferencing bar for medium rooms and BYOD setups. It combines a three-camera panoramic array with 4K video, an 8-microphone beamforming array and four speakers, and it supports Microsoft Teams and Zoom. Procure.ae supplies it across the UAE.

The PanaCast 55 VBS uses three cameras in a panoramic array with a 180° horizontal field of view and up to 3840 x 1080 px camera resolution. Intelligent Zoom provides up to 6x lossless digital zoom, while Virtual Director, Dynamic Composition and Multi-stream Dynamic Composition keep participants framed. Automatic speaker detection, noise reduction, echo cancellation and non-speech noise suppression support clear audio. The 8-microphone beamforming array is certified for rooms up to 4.5 m x 6 m, and the optional PanaCast SpeakerMic extends audio coverage from 7 m to 11 m.

The bar suits medium meeting rooms and BYOD setups. It supports Microsoft Teams and Zoom, Microsoft Teams Room for Android and Zoom Rooms, and it can run in appliance or BYOD mode. Administrators manage it through Jabra+, the Jabra Web Console and the VaaS Admin Portal. The PanaCast 55 VBS Bar Only is the bar without the optional audio extension, so buyers who need more coverage can add the PanaCast SpeakerMic.

Resolution
3840 x 1080 px (camera, up to 4K di...
Type
Video Conferencing Bar
Weight
2.26 kg
  • 180° panoramic view
  • 4K video
  • AI framing
Price
On request · best price
1
Download spec sheet (PDF) Manufacturer datasheet (PDF)
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request

Key features

01
180° panoramic view
three cameras give a 180° horizontal and 54° vertical field of view.
02
4K video
camera resolution up to 3840 x 1080 px with Vivid HDR.
03
AI framing
Intelligent Zoom, Virtual Director and Dynamic Composition keep people in frame.
04
8-mic beamforming audio
pickup up to 7 m, or up to 11 m with the PanaCast SpeakerMic.
05
Four-speaker output
2 x 50 mm woofers and 2 x 20 mm tweeters, 80 Hz to 20,000 Hz.
06
Teams and Zoom
works with Microsoft Teams, Zoom, Microsoft Teams Room for Android and Zoom Rooms.
07
Remote management
Jabra+, Jabra Web Console and VaaS Admin Portal with secure boot lockdown.
08
Built-in sensors
integrated people count plus temperature, humidity, CO2 and TVOC sensors.

Specifications

22 specifications
General
CompatibilityMicrosoft Teams, Zoom, Microsoft Teams Room for Android, Zoom Rooms
Key Features180° panoramic 3-camera array, 4K video, AI framing, 8-mic beamforming array, Teams and Zoom compatible, Jabra+ remote management
ModelPanaCast 55 VBS Bar Only
TypeVideo Conferencing Bar
What's in the BoxVideo bar, power supply, wall mount, privacy cover with sensor, cable compartment cover, HDMI cable (1.83 m), regional power cable
Display
Camera3 cameras in a panoramic array, 180° horizontal and 54° vertical field of view
Resolution3840 x 1080 px (camera, up to 4K display output)
ZoomUp to 6x lossless digital zoom
Audio
Frequency Response80 Hz to 20,000 Hz
Microphone8-microphone beamforming array, pickup up to 7 m (11 m with PanaCast SpeakerMic)
Speaker Configuration4 speakers: 2 x 50 mm woofers, 2 x 20 mm tweeters
Connectivity
BluetoothBluetooth 5.1
EthernetRJ45 (Auto-MDIX)
Input Voltage100–240 V AC; 12 V, 5 A
PortsHDMI out × 2, HDMI in, USB-A × 1, USB-C × 2, Ethernet (RJ45), Aux-out
Physical
Dimensions730 x 77 x 146 mm
MountingWall mount included
Operating Humidity15% to 80% RH
Operating Temperature5 to 35 °C
Weight2.26 kg
Compliance
Safe Security FeaturesKensington lock slot, secure boot, vendor lock, remote log retrieval
Warranty2 years

Questions

Can’t find your answer? Ask on WhatsApp

What room size is the Jabra PanaCast 55 VBS Bar Only designed for?
The bar is designed for medium rooms and BYOD setups. Jabra certifies its 8-microphone array for rooms up to 4.5 m x 6 m, and the optional PanaCast SpeakerMic extends audio coverage to 11 m for larger spaces.
Does the PanaCast 55 VBS work with Microsoft Teams and Zoom?
Yes. The bar works with Microsoft Teams and Zoom and supports Microsoft Teams Room for Android and Zoom Rooms. It also has a BYOD mode, so participants can join from their own laptop.
Can the PanaCast 55 VBS be wall mounted?
Yes. A wall mount is included in the box, and the bar has a cable compartment cover. The manufacturer's specifications do not state a VESA pattern for the bar itself.
What can I connect to the PanaCast 55 VBS?
The bar has two HDMI outputs for a display, an HDMI input for content sharing, and an external USB camera can be added as a secondary camera. Apple AirPlay works with Zoom only and Microsoft Teams Cast works with Teams only.
How is the PanaCast 55 VBS managed across several rooms?
Administrators can manage the bar remotely through Jabra+, the Jabra Web Console over HTTPS, and the VaaS Admin Portal. Log retrieval and authenticated access to admin settings are included. Microsoft and Zoom based account authentication is supported for VaaS administration.
