iiyama ProLite 15.6-inch Android Touch Panel PC – TW1623AS-B3P
The iiyama ProLite TW1623AS-B3P is a 15.6-inch Full HD touch panel PC with Android 16, 10-point PCAP touch and Power over Ethernet, built for meeting rooms, information points and hospitality spaces. It has a 1920 x 1080 IPS display, 4GB RAM and 32GB storage, and integrates with the iiSignage² content management system. Procure.ae supplies the TW1623AS-B3P across the UAE.
The 15.6-inch IPS panel runs at 1920 x 1080 with 450 nits panel brightness, 1,000:1 static contrast and 170-degree viewing angles. Its projected capacitive touch layer supports 10 touch points when the integrated OS is used, with finger, glove or capacitive stylus input. The RK3568 quad-core processor with 4GB LPDDR4X memory and 32GB eMMC storage runs Android 16, so apps can be installed on the unit. Two 2 W speakers and a built-in microphone are included, and kiosk mode is supported.
Power over Ethernet (IEEE 802.3at, 30 W) carries power and data over one RJ45 cable, which simplifies installation where many cables would interfere with the environment. The iiSignage² CMS manages messages and displays remotely, and the unit operates in landscape, portrait or face-up orientation with a 100 x 100 mm VESA pattern. Unlike the TW1625LASC-B3PNR, the manufacturer's TW1623AS-B3P listing does not include an NFC/RFID reader or RGB LED bar.
Screen Size
15.6 inch
Resolution
1920 x 1080 (Full HD)
Brightness
450 nits
Touch Technology
PCAP
- 10-point PCAP touch
- Android 16 platform
- Power over Ethernet
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
10-point PCAP touch
projected capacitive touch supports 10 touch points with finger, glove or capacitive stylus input.
02
Android 16 platform
pre-installed Android 16 lets you install applications directly on the device.
03
Power over Ethernet
PoE (IEEE 802.3at, 30 W) provides power and data through one RJ45 cable.
04
iiSignage² CMS support
the iiSignage² content management system controls messages and displays remotely.
05
Built-in microphone and speakers
a microphone and two 2 W speakers are built in.
06
Kiosk mode
kiosk mode is supported, with a maximum non-stop operating time of 24/7.
07
Flexible orientation
the unit operates in landscape, portrait or face-up orientation with a 100 x 100 mm VESA pattern.
08
Protected glass
1.8 mm glass with 6H hardness protects the display.
Specifications
32 specificationsGeneral
Key FeaturesKiosk mode, iiSignage² CMS, Power over Ethernet, 10-point touch, 6H glass, 24/7 operation, Android 16 app installation
ModelTW1623AS-B3P
TypeTouch Panel PC
Display
Aspect Ratio16:9
Brightness450 nits
Color Depth8-bit (16.7 million colours)
Contrast Ratio1,000:1
OrientationLandscape, portrait, face-up
Panel TechnologyIPS
Resolution1920 x 1080 (Full HD)
Response Time30 ms
Screen Size15.6 inch
Touch Points10-point multi-touch
Touch TechnologyPCAP
Viewing Angle170° horizontal / 170° vertical
Performance
Operating SystemAndroid 16
ProcessorRockchip RK3568 quad-core Cortex-A55, up to 2.0 GHz
RAM4 GB LPDDR4X
Storage32 GB eMMC
Audio
MicrophoneBuilt-in × 1
Speaker Output2 × 2 W
Connectivity
BluetoothBluetooth 5.2
PoEIEEE 802.3at, 30 W
PortsRJ45 LAN × 1, mini HDMI × 1, USB × 3, 3.5 mm audio jack × 1
Wi-Fi802.11a/b/g/n/ac
Power
Power Consumption9 W (typical)
Power SourceDC 12 V external power supply
Physical
Dimensions387 x 244 x 30.5 mm (W x H x D)
Duty Cycle24/7
VESA Mount100 x 100 mm
Weight1.5 kg (without box)
Compliance
CertificationsCE, EAC, RoHS, ErP, WEEE, REACH, UKCA
Downloads
Manufacturer documents for the iiyama ProLite 15.6-inch Android Touch Panel PC – TW1623AS-B3P — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
Does the TW1623AS-B3P run Android apps?
Yes. It runs Android 16 on a Rockchip RK3568 quad-core processor with 4GB LPDDR4X memory and 32GB eMMC storage, so applications can be installed directly on the unit. Kiosk mode is supported, and the manufacturer lists Play Store, Chrome and Gmail among the applications.
Can the TW1623AS-B3P be powered over Ethernet?
Yes. The RJ45 LAN port supports Power over Ethernet to IEEE 802.3at at up to 30 W, so one cable carries both data and power. The unit can also use an external DC 12 V power supply, with typical power usage of 9 W.
Is the TW1623AS-B3P suitable for a meeting room booking panel?
Yes. The manufacturer positions it for meeting rooms, information points and hospitality spaces. Its 15.6-inch Full HD touch screen, built-in microphone and Android apps suit booking and information displays, and its viewing angles are 170 degrees horizontal and vertical.
Does the TW1623AS-B3P support VESA mounting?
Yes. It has a VESA mounting pattern of 100 x 100 mm and operates in landscape, portrait or face-up orientation. It measures 387 x 244 x 30.5 mm and weighs 1.5 kg without its box, so Procure.ae can confirm the most suitable mount for your installation.
