Huawei CloudLink Bar 310 integrated video conferencing endpoint with Full HD PTZ cameraHuawei
Meeting Room SolutionsSKU CloudLink Bar 310

Huawei CloudLink Bar 310 Integrated Video Conferencing Endpoint

The Huawei CloudLink Bar 310 is an integrated video conferencing endpoint for small and medium-sized meeting rooms. It has a built-in Full HD PTZ camera with 12x optical zoom, a microphone array and an HD codec, plus two HDMI video outputs. Procure.ae supplies the CloudLink Bar 310 across the UAE.

The Bar 310 combines a dual-lens Full HD PTZ camera with 12x optical zoom and a built-in microphone array. Its smart eye function keeps the speaker centered within the frame. The unit supports H.265, H.265 SVC and H.264 video codecs, plus H.263 and H.263+. Audio codecs include Opus, AAC-LD, G.722.1C and G.711. It has two HDMI video outputs, built-in Wi-Fi and a 10/100/1000M LAN port, and it runs HarmonyOS.

The manufacturer positions the Bar 310 for small and medium-sized meeting rooms. It supports H.323 and SIP calls, so it can join video conferencing services that use either protocol. A dedicated RJ45 port connects a touch panel, while a 10/100/1000M LAN port and built-in Wi-Fi cover network connection. The manufacturer's specifications do not state mounting options, so confirm those with Procure.ae before ordering.

Resolution
1920 x 1080 (Full HD)
Type
Integrated Video Conferencing Endpoint
  • Full HD PTZ camera
  • Smart eye framing
  • Built-in microphone array
Price
On request · best price
1
Download spec sheet (PDF)
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request

Key features

01
Full HD PTZ camera
A dual-lens Full HD PTZ camera with 12x optical zoom.
02
Smart eye framing
The smart eye function keeps the speaker centered within the camera frame.
03
Built-in microphone array
The microphone array is built into the unit.
04
Integrated HD codec
An HD codec is built into the endpoint for video calls.
05
H.265 and H.264 video
Supports H.265, H.265 SVC, H.264 HP, H.264 BP, H.264 SVC, H.263 and H.263+ video protocols.
06
H.323 and SIP support
ITU-T H.323 and IETF SIP are the supported multimedia protocols.
07
Dual HDMI video output
Two HDMI video outputs connect the endpoint to displays.
08
Wi-Fi and LAN
Built-in Wi-Fi and a 10/100/1000M RJ45 LAN port for network connection.

Specifications

15 specifications
General
Key FeaturesDual-lens Full HD PTZ camera, 12x optical zoom, smart eye speaker framing, built-in microphone array, H.265 SVC and H.264 video, H.323 and SIP support, HarmonyOS, built-in Wi-Fi
ModelCloudLink Bar 310
TypeIntegrated Video Conferencing Endpoint
Display
CameraDual-lens Full HD PTZ, 12x optical zoom
Resolution1920 x 1080 (Full HD)
Zoom12x optical
Performance
Operating SystemHarmonyOS
Audio
Audio CodecsOpus, AAC-LD, G.729A, G.722, G.722.1C, G.711U, G.711A
Audio InBuilt-in microphone array, 3.5 mm × 1, HD-AI × 1, HDMI × 1 (audio), USB-C × 1 (audio)
Audio Out3.5 mm × 1, HDMI × 1 (audio)
MicrophoneBuilt-in microphone array
Connectivity
ConnectivityBuilt-in Wi-Fi, 10/100/1000M Ethernet
OutputsHDMI × 2 (video)
PortsHDMI Out × 2, USB 3.0 × 1, RJ45 LAN × 1, RJ45 touch × 1, Wi-Fi (built-in)
ProtocolsITU-T H.323, IETF SIP

Questions

Can’t find your answer? Ask on WhatsApp

Is the CloudLink Bar 310 designed for small and medium-sized meeting rooms?
Yes. The manufacturer positions the CloudLink Bar 310 for small and medium-sized meeting rooms. It combines a camera, a microphone array and an HD codec in one unit, so a separate codec box is not needed.
Does the CloudLink Bar 310 support SIP and H.323?
Yes. It supports ITU-T H.323 and IETF SIP multimedia protocols. Its video codecs include H.265, H.265 SVC and H.264, and its audio codecs include Opus, AAC-LD and G.722. Both protocols are listed in the manufacturer's specifications for the CloudLink Bar 310.
How does the camera keep the speaker in frame?
The Bar 310 uses a dual-lens Full HD PTZ camera with a 12x optical zoom main lens and a smart eye function. The manufacturer says this keeps the speaker centered within the frame.
How many HDMI outputs does the CloudLink Bar 310 have?
It has two HDMI video outputs. Its audio inputs include HDMI, USB-C, 3.5 mm and HD-AI ports, and its audio outputs include HDMI and 3.5 mm. The unit also has a built-in microphone array and a 12x optical zoom camera.
Can I buy the CloudLink Bar 310 in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
