Specification

Technical specifications

Scanner type

Flatbed; ADF

Digital sending standard features

• Scan to email; Scan to PC; Scan to Network

Digital sending optional features

• Send to email
• Send to network folder
• Send to PC

Scan resolution, optical

Up to 600 x 600 dpi (colour and monochrome, ADF); Up to 1200 x 1200 dpi (colour and monochrome, flatbed)

Duty cycle (daily)

4,000 pages (ADF), 100 pages (Flatbed)

Bit depth

24-bits external 48-bits internal

Levels of grayscale

256

Multifeed detection

Yes

Task speed

• OCR A4 text page (ADF, 300 dpi, colour, RTF): 6.51 sec for single image scan, 4.45 sec for single image save
• A4 to email (ADF, 300 dpi, colour, PDF): 6.43 sec for single image scan, 1.56 sec for single image send
• OCR A4 text page (flatbed, 300 dpi, colour, RTF): 7.89 sec for single image scan, 4.43 sec for single image save
• A4 to email (flatbed, 300 dpi, colour, PDF): 7.89 sec for single image scan, 1.39 sec for single image send
• Slides to file and negative to file are not supported

Scan size, maximum

216 x 356 mm

Media types

Paper (banner, inkjet, photo, plain), envelopes, labels, cards (greeting, index)

Media weights, supported ADF

45 to 120 g/m²

Scan file format

For text & images: PDF, JPEG, PNG, BMP, TIFF, Text (.txt), Rich Text (rtf) and searchable PDF

Scan input modes

Scan front-panel function: Save as PDF, Save as JPEG, Email as PDF, Email as JPEG, Send to Cloud, Everyday Scan and Save as Editable Text (OCR); HP Scan in Win OS, HP Easy Scan/ICA in Mac OS and thrid parties applications via TWAIN (USB & Network)

Scanner advanced features

Blank page removal; Auto orientation; Auto colour detect; Auto crop; Auto exposure; Hole removal; Straighten content; Erase edges; Clean up background; Auto threashold; Colour drop out; OCR

Control panel

• 7.11 cm (2.8") touchscreen, 3 buttons (Back, Home, Help)

ADF specifications

Automatic document feeder capacity

Standard, 50 sheets (75 g/m² paper)

Automatic document feeder speed

Up to 30 ppm/60 ipm 1

Scanning options (ADF)

Single pass E-Duplex

Scan size (ADF), maximum

216 x 3100 mm

Scan size (ADF), minimum

105 x 148 mm

Compatible operating systems

Compatible operating systems

Windows 7 or higher
Mac: OS X El Capitan 10.11

Mac compatible

• Yes

Connectivity

Connectivity, standard

• Hi-Speed USB 2.0 and USB 3.0
• Built-in Fast Ethernet 10/100/1000 Base-TX network port

Twain version

TWAIN Certified. Version 2.1

Power and operating requirements

Voltage

Input Voltage: 100 to 240 VAC

Power consumption

6.11 watts (ready), 1.35 watts (sleep), 0.05 watts (auto-off), 0.05 watts (off)

Energy efficiency

ENERGY STAR® certified

Operating temperature range

10 to 35°C

Dimensions and weight

Dimensions (W x D x H)

520 x 387 x 145 mm

Weight

5.98 kg
