Specification

Technical specifications

Scanner type

Flatbed, ADF

Scan resolution, optical

Up to 600 dpi (colour and monochrome, ADF); Up to 1200 dpi (colour and monochrome, flatbed)

Duty cycle (daily)

3,000 pages (ADF)

Bit depth

24-bits external 48-bits internal

Levels of grayscale

256

Multifeed detection

Yes

Task speed

• 10 x 15 cm colour photo to file (200 dpi, 24-bit, TIFF): about 9.2 sec for single image scan
• 10 x 15 cm colour photo to email (150 dpi, 24-bit): about 8.9 sec for single image scan
• A4 PDF to email (300 dpi, 24-bit): about 13.2 sec for single image scan
• OCR A4 to RTF (200 dpi, 24-bit): about 13.9 sec for single image scan
• (Does not support slides to file)

Scan size, maximum

216 x 297 mm

Media types

Paper (banner, inkjet, photo, plain), envelopes, labels, cards (greeting, index)

Media weights, supported ADF

45 to 120 g/m²

Scan file format

For text & images: PDF, JPEG, PNG, BMP, TIFF, TXT (text), RTF (rich text) and searchable PDF

Scan input modes

Scan front-panel function for Save as PDF, Save as JPEG, Email as PDF, Email as JPEG, Send to Cloud, Everyday Scan and Save as Editable Text (OCR). HP Scan in Windows OS, HP Easy Scan/ICA in Mac OS and thrid parties applications via TWAIN.

Control panel

• 2-line LCD
• 5 buttons (Simplex/Duplex, Power, Cancel, Back and Tools/Maintenance)

ADF specifications

Automatic document feeder capacity

Standard, 50 sheets

Automatic document feeder speed

Up to 25 ppm/50 ipm (300 dpi) 2

Scanning options (ADF)

Single pass E-Duplex

Scan size (ADF), maximum

216 x 3100 mm

Scan size (ADF), minimum

105 x 148 mm

Compatible operating systems

Compatible operating systems

Windows 10 (32-bit/64-bit), Windows 8.1 (32-bit/64-bit), Windows 8 (32-bit/64-bit), Windows 7 (32-bit/64-bit)
Mac OS X Mavericks 10.9, OS X Yosemite 10.10

Mac compatible

• Yes

Connectivity

Connectivity, standard

• Hi-Speed USB 2.0 and USB 3.0

Twain version

TWAIN Certified. Version 2.1

Power and operating requirements

Voltage

Input voltage: 90 to 264 VAC, 50/60 Hz

Power consumption

4.51 watts (ready), 1.40 watts (sleep), 0.22 watts (auto-off), 0.22 watts (manual-off) 1

Energy efficiency

ENERGY STAR® certified

Operating temperature range

10 to 35°C

Operating humidity range

15 to 80% RH (non-condensing)

Dimensions and weight

Dimensions (W x D x H)

460 x 387 x 145 mm

Weight

5.58 kg
