Specification

Technical specifications

Scanner type

Sheetfed

Scan resolution, optical

Up to 600 dpi (colour and monochrome, sheet-feed)

Duty cycle (daily)

Recommended for 3,500 pages per day

Bit depth

24-bits external/48-bits internal

Levels of grayscale

256

Task speed

• 10 x 15 cm colour photo to file (200 dpi, 24-bit, tiff): about 6.27 sec for single image scan
• OCR A4 (200dpi, 24-bit to RTF): about 7.45 sec for single image scan
• 10 x 15 cm colour photo to email (150 dpi, 24-bit): about 5.95 sec for single image scan, about 1.08 sec for single image send to email, totally 7.03 sec
• A4 PDF to email (300 dpi, 24-bit): about 7.36 sec for single image scan, about 1.7 sec for single image send to email, totally 9.06 sec

Media types

Cut sheet paper, printed paper (laser and ink), pre-punched paper, bank checks, business cards, freight bills, carbonless forms, previously stapled media with staple removed

Media weights, supported ADF

40 to 413 g/m²

Scan file format

For text and images: PDF, JPEG, PNG, BMP, TIFF, TXT (Text), RTF (Rich Text) and searchable PDF

Scan input modes

One default scan mode on front-panel for HP scan in Win OS, HP Easy Scan/ICA in Mac OS and third parties applications via TWAIN, ISIS and WIA

Scanner advanced features

Auto colour detect; Auto crop; Auto exposure; Auto orientation; OCR; Edge removal; Background cleanup; Remove hole; Colour drop out; Straighten the page; Scan to cloud; Scan to email; PDF security; Misfeed detection advance setting

Control panel

• Scan button, Cancel button, Power button with a LED and a LED for Error indication

ADF specifications

Automatic document feeder capacity

50 sheets

Automatic document feeder speed

Up to 35 ppm/70 ipm 3

Scan size (ADF), maximum

216 x 3100 mm

Scan size (ADF), minimum

50.8 x 74 mm

Compatible operating systems

Compatible operating systems

OS X El Capitan 10.11
Microsoft® Windows® 10, 8.1, 8, 7: 32-bit/64-bit

Mac compatible

• Yes

Connectivity

Connectivity, standard

• Hi-Speed USB 2.0 and USB 3.0

Connectivity, optional

• USB 2.0 port for Wi-Fi accessory

Twain version

TWAIN version 2.1

Power and operating requirements

Voltage

Input Voltage: 90 to 264 VAC, 50/60 Hz

Power consumption

4.2 watts (ready), 0.7 watts (sleep), 0.1 watts (off), 0.1 watts (auto-off) 2

Operating temperature range

10 to 35ºC

Operating humidity range

15 to 80% RH (non-condensing)

Dimensions and weight

Dimensions (W x D x H)

310 x 198 x 190 mm

Weight

3.4 kg
