Specification

Technical specifications

Scanner type

Sheetfed

Scan resolution, optical

Up to 600 dpi (colour and monochrome, sheet-feed)

Duty cycle (daily)

Recommended for 6000 pages per day

Bit depth

24-bits external/48-bits internal

Levels of grayscale

256

Task speed

• 10 x 15 cm colour photo to file (200 dpi, 24-bit, tiff): about 5.18 sec for single image scan
• 10 x 15 cm colour photo to email (150 dpi, 24-bit): about 4.98 sec for single image scan, about 1.43 sec for single image send to email, totally 6.41 sec
• A4 PDF to email (300 dpi, 24-bit): about 6.63 sec for single image scan, about 3 sec for single image send to email, totally 9.63 sec

Media types

Cut sheet paper, printed paper (laser and ink), pre-punched paper, bank checks, business cards, freight bills, carbonless forms, plastic carrier sheets for easily damaged documents, previously stapled media with staple removed

Media weights, supported ADF

40 to 413 g/m²

Scan file format

For text & images: ePub 3.0, HTML 4.0, Excel file format (*.xls, *.xlsx), PowerPoint file format (*.pptx), Word (*.docx), WordPerfect (*.wpd), searchable PDF, JPEG, PNG, BMP, TIFF, Text (.txt), Rich Text (rtf), XML and XPS

Scan input modes

Two scan modes (simplex/duplex) on front-panel for HP SDSS in Win OS and third parties applications via TWAIN, ISIS and WIA

Scanner advanced features

Auto colour detect; Auto crop; Auto exposure; Auto orientation; OCR; Edge removal; Background cleanup; Remove hole; Colour drop out; Straighten the page; Scan to cloud; Scan to email; PDF security; Misfeed detection advance setting; Batch processing; Barcode; Scan to multiple destinations

Control panel

• 2-line 16 character per line LCD display, Simplex button, Duplex button, Cancel button, Power button with a LED and Tool button

ADF specifications

Automatic document feeder capacity

80 sheets

Automatic document feeder speed

Up to 50 ppm/100 ipm (black & white, 300ppi) 3

Scan size (ADF), maximum

216 x 3100 mm

Scan size (ADF), minimum

50.8 x 50.8 mm

Compatible operating systems

Compatible operating systems

Microsoft® Windows® 10, 8.1, 8, 7: 32-bit/64-bit

Mac compatible

• No

Connectivity

Connectivity, standard

• Hi-Speed USB 2.0 and USB 3.0

Connectivity, optional

• USB 2.0 port for Wi-Fi accessory

Twain version

TWAIN version 2.1

Power and operating requirements

Voltage

Input Voltage: 90 to 264 VAC, 50/60 Hz

Power consumption

4.4 watts (ready), 0.8 watts (sleep), 0.1 watts (off), 0.1 watts (auto-off) 2

Operating temperature range

10 to 35ºC

Operating humidity range

15 to 80% RH (non-condensing)

Dimensions and weight

Dimensions (W x D x H)

310 x 198 x 190 mm

Weight

3.8 kg
