HP ProDesk Small Form Factor PC 400-G4

Specification

System features

Operating system

Windows 10 Pro 64 – HP recommends Windows 10 Pro. 1
Windows 10 Home 64 1
Windows 10 Home Single Language 64 1
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) 3
FreeDOS 2.0

Processor family

7th Generation Intel® Core™ i3 processor (i3-7100, i3-7300, i3-7320 models)
7th Generation Intel® Core™ i5 processor (i5-7500, i5-7600 models)
7th Generation Intel® Core™ i7 processor (i7-7700 model)
7th Generation Intel® Pentium® processor (G4560, G4600, G4620 models)
7th Generation Intel® Celeron® processor (G3930, G3950 models)
6th Generation Intel® Core™ i7 processor (i7-6700 model)
6th Generation Intel® Core™ i3 processor (i3-6100 model)
6th Generation Intel® Core™ i5 processor (i5-6500 model) 4,5

Processor

Intel® Core™ i7-7700 with Intel HD Graphics 630 (3.6 GHz, up to 4.2 GHz with Intel Turbo Boost, 8 MB cache, 4 cores)
Intel® Core™ i5-7500 with Intel HD Graphics 630 (3.4 GHz, up to 3.8 GHz with Intel Turbo Boost, 6 MB cache, 4 cores)
Intel® Core™ i3-7100 with Intel HD Graphics 630 (3.9 GHz, 3 MB cache, 2 cores)
Intel® Pentium® G4560 with Intel HD Graphics 610 (3.5 GHz, 3 MB cache, 2 cores)
Intel® Celeron™ G3930 with Intel HD Graphics 610 (2.9 GHz, 2 MB cache, 2 cores)
Intel® Core™ i7-6700 with Intel HD Graphics 530 (3.4 GHz, up to 4.0 GHz with Intel Turbo Boost, 8 MB cache, 4 cores)
Intel® Core™ i5-6500 with Intel HD Graphics 530 (3.2 GHz, up to 3.6 GHz with Intel Turbo Boost, 6 MB cache, 4 cores)
Intel® Core™ i3-6100 with Intel HD Graphics 530 (3.7 GHz, 3 MB cache, 2 cores) 4,19

Chipset

Intel® H270

Form factor

Small form factor

Management features

HP Client Catalog; LANDESK Management; HP SoftPaq Download Manager (SDM); HP System Software Manager (SSM); HP BIOS Config Utility (BCU); HP MIK for Microsoft SCCM 15, 22

Memory

Maximum memory

32 GB DDR4-2400 SDRAM
(Transfer rates up to 2400 MT/s )

Memory Slots

2 DIMM

Storage

Internal drive bays

One 9 mm slim ODD; One 2.5" HDD or One 3.5" HDD 21

Internal drive

500 GB up to 2 TB 3.5" SATA HDD (7200 rpm) 7
128 GB up to 256 GB SATA SSD 7

Display and graphics

Graphics

Integrated:
Intel® HD Graphics 530
Intel® HD Graphics 630
Intel® HD Graphics 610 9,10,11
Discrete:

NVIDIA® GeForce® GT730 (2 GB)

Expansion features

Ports

Front:
1 SD 3 card reader (optional)
1 headset connector
2 USB 3.1 Gen 1
Back:
1 audio-in
1 audio-out
1 DisplayPort™ 1.2
1 power connector
1 RJ-45
1 VGA
2 USB 3.1 Gen 1
4 USB 2.0
Back (optional):
1 PS/2 port
1 serial 18

Expansion slots

Turbo Drive (M.2 PCIe)
1 M.2 2230 for wireless NIC
PCI Express x16 (v3.0)(wired as a x4) 2.5" low profile, 6.6" length, 35 W max power
PCI Express x16 (v3.0) 2.5" low profile, 6.6" length, 35 W max power 23

Media devices

Audio

Conexant CX20632 codec with universal audio jack and 2W internal speaker, headset and headphone front ports (3.5 mm), multi-streaming capable

Communications

Network interface

LANRealtek RTL8111 HSH GbE LOM network connection
WLAN (optional)Intel® 7265 802.11ac (2x2) wireless with Bluetooth® M.2 combo card non-vPro™ 8

Power and operating requirements

Energy efficiency

ENERGY STAR® certified and EPEAT® registered configurations available 16

Power supply

• 180 W internal power supply, up to 85% efficiency, active PFC

24

Dimensions and weight

Dimensions (W x D x H)

9.5 x 29.6 x 27 cm
(Dimensions are for tower orientation)

Weight

4.6 kg
(Exact weight depends on configuration)
