Hisense 86-inch 4K Outdoor Air-Conditioned Digital Signage Kiosk – 86SOA25PT

The Hisense 86SOA25PT is a 86-inch outdoor digital signage kiosk with a 4K UHD 2500-nit screen and an IP65 air-conditioned enclosure. It suits large outdoor plazas, transport hubs and event entrances. Procure.ae supplies Hisense displays in the UAE and can confirm current availability of this model.

The 86SOA25PT from the Hisense SOA25PT Series has a 86-inch 4K UHD panel at 3840 x 2160 pixels, with 2500 nits of brightness and a 1,200:1 contrast ratio. The screen runs in portrait orientation with a touch foil overlay that supports 10 touch points, and it has an 8 ms response time. It is rated for 24/7 operation with a 50,000-hour backlight life cycle and a light sensor that adjusts brightness automatically. An Android 7.1 system with an Amlogic quad-core Cortex-A53 processor at 1.5 GHz, 2 GB DDR4 RAM and 16 GB eMMC storage runs the content.

The 86SOA25PT suits outdoor locations, with a air-conditioned enclosure rated IP65 for operation from -40 to 55 °C and 5% to 95% RH. It connects over Wi-Fi or LAN, with optional 3G/4G, and its HDMI, USB 2.0, TF card and RS232 ports cover media playback and serial connectivity. Its 1310 x 2852 x 300 mm dimensions and 450 kg weight should be factored into site planning, and Procure.ae can advise on installation requirements before delivery.

Screen Size
86 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
2500 nits
Touch Technology
Touch foil
  • High-brightness screen
  • IP65 all-weather enclosure
  • Built-in air conditioner
Price
On request · best price
1
Download spec sheet (PDF) Manufacturer datasheet (PDF)
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request

Key features

01
High-brightness screen
The 2500-nit panel with a 1,200:1 contrast ratio stays clear in any lighting conditions.
02
IP65 all-weather enclosure
The IP65 enclosure protects the components in any conditions, all year round.
03
Built-in air conditioner
A built-in air conditioner with overheating protection supports operation from -40 to 55 °C, and the manufacturer states no filter maintenance is required.
04
10-point touch
A touch foil overlay with 10 touch points.
05
Android 7.1 platform
Amlogic quad-core Cortex-A53 processor at 1.5 GHz, 2 GB DDR4 RAM and 16 GB eMMC storage.
06
Connectivity and ports
Wi-Fi or LAN with optional 3G/4G, plus HDMI, USB 2.0, LAN, TF card and RS232 ports.
07
Integrated speaker
A built-in speaker is fitted to the unit.
08
Auto brightness control
A light sensor adjusts the screen brightness to the surrounding light.

Specifications

33 specifications
General
Key Features2500-nit high-brightness screen, IP65 all-weather enclosure, Built-in air conditioner, 10-point touch, Android 7.1, Built-in speaker, Auto brightness control, Wi-Fi or LAN connectivity
Model86SOA25PT
TypeOutdoor Digital Signage Kiosk
Display
Aspect Ratio16:9
Backlight50,000-hour life cycle
Brightness2500 nits
Contrast Ratio1,200:1
OrientationPortrait
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size86 inch
Touch Points10-point multi-touch
Touch TechnologyTouch foil
Viewing Angle178° (H) / 178° (V)
Performance
GraphicsMali-450 GPU
Operating SystemAndroid 7.1
ProcessorAmlogic quad-core Cortex-A53, 1.5 GHz
RAM2 GB DDR4
Storage16 GB eMMC (expandable to 128 GB)
Audio
AudioBuilt-in speaker
Connectivity
ConnectivityWi-Fi or LAN; optional 3G/4G
Input Voltage110/220 V AC, 50/60 Hz
PortsHDMI In × 2, HDMI Out × 1, AV Out × 1, USB 2.0 × 1, LAN × 1, TF card slot × 1, RS232 × 1
Power
Power Consumption2500 W (max)
Power SourceBuilt-in power supply
Physical
ColorBlack
Dimensions1310 x 2852 x 300 mm
Duty Cycle24/7
MaterialGalvanized steel with powder coating; 6.8 mm AR tempered laminated glass
Operating Humidity5% to 95% RH
Operating Temperature-40 to 55 °C
Weight450 kg
Compliance
IP RatingIP65

Downloads

Manufacturer documents for the Hisense 86-inch 4K Outdoor Air-Conditioned Digital Signage Kiosk – 86SOA25PT — datasheets, manuals, drawings and certificates.

Questions

Can’t find your answer? Ask on WhatsApp

Is the 86SOA25PT built for outdoor use?
Yes. The 86SOA25PT is listed for full outdoor working environments, with an IP65 enclosure, an operating temperature of -40 to 55 °C and an operating humidity range of 5% to 95% RH.
How is the 86SOA25PT kept cool?
The 86SOA25PT has a built-in air conditioner with overheating protection. The manufacturer states no filter maintenance is required and rates the unit for operation from -40 to 55 °C in a full outdoor environment.
How bright is the screen for outdoor viewing?
The screen is rated at 2500 nits with a 1,200:1 contrast ratio, and it includes a light sensor that adjusts brightness automatically. The manufacturer states the display keeps content clear in any lighting conditions, with 178° viewing angles.
What operating system and connections does the 86SOA25PT have?
It runs Android 7.1 and connects over Wi-Fi or LAN, with optional 3G/4G. Its ports are HDMI In × 2, HDMI Out × 1, AV Out × 1, USB 2.0 × 1, LAN × 1, TF card slot × 1 and RS232 × 1.
What mounting and installation details apply to the 86SOA25PT?
The manufacturer's specifications do not state a mounting method or VESA pattern for the 86SOA25PT. The unit measures 1310 x 2852 x 300 mm (W x H x D) and weighs 450 kg, so Procure.ae can advise on site requirements before delivery and installation across the UAE.
Can I buy the 86SOA25PT in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
