Dinstar DP70 SIP Door Phone

Dinstar DP70 SIP Door Phone

The Dinstar DP70 SIP Door Phone is a voip & telephony available in the UAE from Procure.ae.

Dinstar DP70 SIP Door Phone is a professional SIP-based communication and access control solution designed for modern IP telephony environments. It enables secure, real-time voice communication while integrating seamlessly with IP-PBX systems such as Asterisk, BroadSoft, and 3CX.

It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.

Type
SIP Video Door Phone / Indoor Touch Pad
Weight
0.47 kg

Key features

01
Full SIP compatibility (RFC3261) with major IP-PBX platforms
02
HD voice quality with echo cancellation and noise reduction
03
Fast deployment with web-based configuration
04
Remote management via web GUI, TR-069, and auto provisioning
05
Secure communication with TLS/SRTP encryption
06
Integration with access control and monitoring systems
07
Reliable performance in commercial and industrial environments

Specifications

General
Key FeaturesAudio and video intercom, H.264 video, Monitors up to 8 IP cameras, Emergency call and security alarm, Lift control
TypeSIP Video Door Phone / Indoor Touch Pad
What's in the BoxIndoor panel, Bracket, Screwing kit, Quick start guide (power adapter not included)
Display
Display7" capacitive touchscreen TFT LCD, 1024 x 600
Performance
Operating SystemLinux
RAM128 MB
Storage ConditionsTemperature: -40 to 70 °C
Audio
Audio CodecsG.711
MicrophoneBuilt-in
Speaker Output1 W (8 ohm)
Connectivity
ConnectivitySIP
Ethernet1 x RJ45, 10/100 Mbps
Inputs8 x doorbell inputs, 8 x alarm inputs
PoE802.3af
ProtocolsSIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPv4, ARP, ICMP
SD Card SlotmicroSD card slot × 1
Serial PortRS-485 × 1
Power
Power Consumption9 W rated, 2 W standby
Power SourcePoE (802.3af) or DC 12 V/2 A
Physical
Dimensions195 x 130 x 14.5 mm
MaterialPlastic front panel
MountingSurface mount, desktop
Operating Humidity10% to 90% RH (non-condensing)
Operating Temperature-10°C to 55°C
Weight0.47 kg
