ClevertouchInteractive Flat PanelsSKU Core by Clevertouch 86"
Clevertouch Core 86-inch 4K Interactive Flat Panel – Core by Clevertouch 86"
The Clevertouch Core by Clevertouch 86-inch is a 4K interactive flat panel for classrooms, meeting rooms and training spaces. It has a 3840 x 2160 display, 50-point touch, Android 16 and access to Google Play Store apps. Procure.ae supplies it in the UAE as an authorised reseller, with delivery and installation.
The 86-inch model has a 3840 x 2160 (4K UHD) LCD panel with 400 nits typical brightness, 5,500:1 contrast and a 6.5 ms response time. Touch is infrared, with 50 continuous touch points and ±2 mm accuracy. Two pens with integrated magnetic holders are included. Inside, a Rockchip RK3576 processor runs Android 16 with 8 GB RAM and 64 GB internal storage, and two front-facing 20 W speakers provide the sound.
The panel supports Windows, Android, Linux, Mac OS X and Chrome, and gives access to Google Play Store apps and video conferencing apps such as MS Teams, Google Meet and Zoom. The LYNX app, with online lesson planning, handwriting recognition and split-screen support, is included. Mounting uses a VESA pattern of 800 x 600 mm. The 65-inch and 75-inch versions share this specification sheet but differ in size, weight and VESA pattern.
Screen Size
86 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
400 nits
Touch Technology
Infrared
- 4K UHD display
- 50-point touch
- Pens and magnetic holders
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
4K UHD display
3840 x 2160 resolution, 5,500:1 contrast ratio and 400 nits typical brightness.
02
50-point touch
Infrared touch with 50 continuous touch points and ±2 mm touch accuracy.
03
Pens and magnetic holders
Two pens included, with integrated magnetic pen holders.
04
Android 16
Android 16 with EDLA certification, 8 GB RAM and 64 GB internal storage.
05
Front speakers
Two front-facing, bass-enhanced 20 W speakers.
06
Wi-Fi and Bluetooth
On-board Wi-Fi 6 and Bluetooth 5.4, with an RJ45 LAN port.
07
Front USB-C port
Provides 65 W without an OPS module installed.
08
Quiet fanless design
Ultra-quiet fanless design for classrooms and meeting rooms.
Specifications
37 specificationsGeneral
CompatibilityWindows, Android, Linux, Mac OS X, Chrome
Key Features4K UHD display, 50-point touch, Android 16 with EDLA certification, 2 pens included, 2 x 20 W speakers, Wi-Fi 6, fanless design, LYNX app
ModelCore by Clevertouch 86"
TypeInteractive Flat Panel
What's in the BoxCORE by Clevertouch display, 3 m HDMI cable
Display
Aspect Ratio16:9
Brightness400 nits
Color Depth8-bit + FRC (1.07 billion colours)
Contrast Ratio5,500:1
Panel TechnologyLCD
Refresh Rate60 Hz
Resolution3840 x 2160 (4K UHD)
Response Time6.5 ms
Screen Size86 inch
Touch Accuracy±2 mm
Touch Points50-point multi-touch
Touch TechnologyInfrared
Viewing Angle178°
Performance
Operating SystemAndroid 16
ProcessorRockchip RK3576 (quad-core A72 + quad-core A53)
RAM8 GB
Storage64 GB internal, expandable
Audio
Speaker Output2 x 20 W
Connectivity
BluetoothBluetooth 5.4
Input Voltage100–240 V AC, 50/60 Hz
OPS Slot1 (Intel spec 80-pin)
PortsHDMI In × 3, HDMI Out × 1, USB-C × 1, USB-A 3.0 × 3, USB-A 2.0 × 1, USB Touch (Type B) × 2, LAN In (RJ45) × 1, RS-232 × 1, Audio In × 1
Wi-FiWi-Fi 6 (on-board)
Power
Standby Power0.5 W or less
Physical
Dimensions1957 x 1159.9 x 98.6 mm
Operating Humidity10% to 90% RH
Operating Temperature0 to 40 °C
Shipping Dimensions2110 x 185 x 1291 mm (L x H x D)
Shipping Weight66.3 kg
VESA Mount800 x 600 mm
Weight50.42 kg
Compliance
CertificationsGoogle EDLA certified (Enterprise Device Licence Agreement)
Downloads
Manufacturer documents for the Clevertouch Core 86-inch 4K Interactive Flat Panel – Core by Clevertouch 86" — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What is the screen size and resolution of the Core by Clevertouch 86"?
It is a 86-inch display with 3840 x 2160 (4K UHD) resolution and a 16:9 aspect ratio. The panel has a 178-degree viewing angle and a 60 Hz refresh rate, with 400 nits typical brightness.
Does it run Android or Windows?
It runs Android 16, which is EDLA certified. The manufacturer also lists compatibility with Windows, Linux, Mac OS X and Chrome, and the display has one OPS slot for a PC module.
Can it run video conferencing apps?
Yes. It gives access to video conferencing apps such as MS Teams, Google Meet and Zoom, along with Google Play Store apps, which the manufacturer lists as certified. Those apps run on the display's own Android 16 system.
What VESA mount does the 86-inch model need?
The 86-inch model uses a VESA mount pattern of 800 x 600 mm and has a net weight of 50.42 kg. Check that the wall mount or stand matches both before installation.
Does it come with pens and a cable?
Yes. Two pens with integrated magnetic holders are included, and the box contains the display and a 3 m HDMI cable. The pens can be kept in the integrated magnetic holders when not in use.
Can I buy the Core by Clevertouch 86" in the UAE?
Request a quote via WhatsApp +971 4 546 5041 or email info@procure.ae.
