ViewSonicDigital SignageSKU CDE9830-E1
Viewsonic CDE9830-E1 - 98" Signage Display – CDE9830-E1
The Viewsonic CDE9830-E1 - 98" Signage Display – CDE9830-E1 is a digital signage available in the UAE from Procure.ae.
The Viewsonic CDE9830-E1 is a premium 98-inch signage display designed for businesses seeking powerful and impactful digital communication. With its ultra-large 4K UHD resolution, this signage solution delivers stunning visuals and vibrant colors, making your content stand out in any environment. Seamlessly integrate this commercial display into conference rooms, retail spaces, or public venues to maximize audience engagement.
It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.
Screen Size
98 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
500 nits
Weight
69.4 kg
- Ultra-Large 98" Screen
- 4K UHD Resolution
- Commercial-Grade Durability
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
Ultra-Large 98" Screen
Captivate audiences with a massive display area ideal for high-traffic environments.
02
4K UHD Resolution
Enjoy crystal-clear visuals with four times the detail of Full HD for sharper images and text.
03
Commercial-Grade Durability
Built for continuous operation, perfect for demanding business applications.
04
Comprehensive Connectivity
Features HDMI, USB, VGA, and wireless casting for flexible device integration.
05
Remote Content Management
Easily update and schedule content from anywhere with integrated management tools.
06
Built-In Speakers
Delivers powerful audio to complement your video and multimedia presentations.
07
Energy-Efficient Design
Reduces operational costs while maintaining top-notch performance.
08
Customizable Scheduling
Automate display timings and content transitions for seamless messaging.
Specifications
40 specificationsGeneral
Key FeaturesAll-in-one solution includes CDE9830 display, Wi-Fi adapter and wall mount, Powerful ViewSonic Embedded Signage Platform (VESP), Integrated RJ45 and USB Wi-Fi, ViewBoard Cast content sharing software, myViewBoard Display app for remote screen sharing
What's in the BoxWi-Fi adapter and wall mount, Remote control with batteries, Quick Start Guide, Power cable, HDMI Cable, USB-C cable, Screws and RS232 cable
Display
Aspect Ratio16:9
BacklightDirect LED
Bezel Size25 mm (0.98 in)
Brightness500 nits
Color Depth10-bit (1.07 billion colours)
Contrast Ratio1,200:1 (typ.), 5,000:1 (DCR)
OrientationLandscape & Portrait
Panel TechnologyADS
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size98 inch
Viewing Angle178° (H) / 178° (V)
Performance
Operating SystemAndroid 11
ProcessorAmlogic T982
RAM4 GB
Storage32 GB
Audio
Audio OutSPDIF out × 1
Speaker Output2 × 10 W
Connectivity
BluetoothBuilt-in
EthernetRJ45 × 1
HDMI InputsHDMI In × 3
HDMI OutputsHDMI Out × 1
Input Voltage100–240 V AC
Serial PortRS-232 × 1
USB PortsUSB 3.0 × 1, USB 2.0 × 1
USB-C PortsUSB-C × 1
Wi-FiBuilt-in
Power
Power Consumption190 W (typical)
Standby Power≤ 0.5 W
Physical
Dimensions2212.9 x 1268.4 x 79 mm
Duty Cycle24/7
Operating Humidity10% to 90% RH
Operating Temperature0°C to 40°C
Shipping Dimensions2360 x 1425 x 280 mm
Surface ProtectionAnti-glare, 3H hardness, 25% haze
VESA Mount800 x 600 mm, M8 x 25 mm
Weight69.4 kg
Compliance
Warranty3 years (parts, labor and backlight)
Downloads
Manufacturer documents for the Viewsonic CDE9830-E1 - 98" Signage Display – CDE9830-E1 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What is the ViewSonic digital signage used for?
The Viewsonic CDE9830-E1 is a premium 98-inch signage display designed for businesses seeking powerful and impactful digital communication.
Does it include installation and warranty?
Procure.ae can arrange installation and provides manufacturer-backed warranty support. Contact us for the full warranty details applicable to this model.
What is this display used for?
It's a commercial digital signage display — ideal for menus, advertising, wayfinding, and information screens in retail, offices, and public spaces.
Can it run continuously for long hours?
Yes — commercial signage panels like this are built for extended daily operation; ask us for the exact operating-hours rating on this model.
How is the on-screen content managed?
