Viewsonic CDE8630-W1 - 86" Signage Display – CDE8630-W1

The Viewsonic CDE8630-W1 - 86" Signage Display – CDE8630-W1 is a digital signage available in the UAE from Procure.ae.

The Viewsonic CDE8630-W1 is an impressive 86-inch signage display engineered for high-impact digital signage in commercial and educational environments. Designed with an ultra-large 4K UHD screen, this display delivers stunning image clarity and vibrant colors, ensuring your content stands out in any setting. The CDE8630-W1 offers advanced wireless connectivity and seamless content management tools, making it easy to update and customize your messaging.

It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.

Screen Size

86 inch

Resolution

3840 x 2160 (4K UHD)

Brightness

450 nits

Weight

43.2 kg

Key features

86-Inch 4K UHD Display

Offers ultra-high definition visuals for clear, vibrant presentations and signage.

Wireless Content Sharing

Easily share content from devices without cables for seamless collaboration.

Integrated Media Player

Allows automated playback of multimedia content directly from USB drives.

Remote Device Management

Enables centralized control and monitoring for multiple displays.

Multiple Connectivity Options

Features HDMI, USB, and LAN ports for versatile input and output support.

Energy-Efficient Performance

Designed to reduce power consumption while maintaining top-notch image quality.

Commercial-Grade Durability

Built for 24/7 operation in demanding public environments.

Thin Bezel Design

Maximizes screen space and creates a modern, sleek look ideal for any venue.

Specifications

General
Key Features	All-in-one solution includes ViewBoard display and Wi-Fi adapter, Powerful ViewSonic Embedded Signage Platform (VESP), Integrated RJ45 and USB Wi-Fi, ViewBoard Cast content sharing software, myViewBoard Display app for remote screen sharing
What's in the Box	CDE8630 Wireless Presentation Display, Wi-Fi adapter, Remote control with batteries, Quick Start Guide, Power cable, HDMI Cable, USB-C cable, Wall Mount, Screws and RS232 cable

Display
Aspect Ratio	16:9
Backlight	Direct LED
Bezel Size	14.7 mm
Brightness	450 nits
Color Depth	10-bit (1.07 billion colours)
Contrast Ratio	1,200:1 (typ.), 5,000:1 (DCR)
Orientation	Landscape & Portrait
Panel Technology	ADS
Resolution	3840 x 2160 (4K UHD)
Response Time	8 ms
Screen Size	86 inch
Viewing Angle	178° (H) / 178° (V)

Performance
Operating System	Android 11
Processor	Amlogic T982
RAM	4 GB
Storage	32 GB

Audio
Audio Out	SPDIF out × 1
Speaker Output	2 × 10 W

Connectivity
Bluetooth	Built-in
Ethernet	RJ45 × 1
HDMI Inputs	HDMI In × 3
HDMI Outputs	HDMI Out × 1
Input Voltage	100–240 V AC
Serial Port	RS-232 × 1
USB Ports	USB 3.0 × 1, USB 2.0 × 1
USB-C Ports	USB-C × 1
Wi-Fi	Built-in

Power
Power Consumption	172 W (typical)
Standby Power	< 0.5 W

Physical
Dimensions	1930.8 x 1101.8 x 81.6 mm
Duty Cycle	24/7
Operating Humidity	10% to 90% RH
Operating Temperature	0°C to 40°C
Shipping Dimensions	2110 x 1227 x 225 mm
Surface Protection	Anti-glare, 3H hardness, 25% haze
VESA Mount	800 x 600 mm
Weight	43.2 kg

Compliance
Warranty	3 years (parts, labor and backlight)
