ViewSonicDigital SignageSKU CDE8630-E1
Viewsonic CDE8630-E1 - 86" Signage Display – CDE8630-E1
The Viewsonic CDE8630-E1 - 86" Signage Display – CDE8630-E1 is a digital signage available in the UAE from Procure.ae.
The Viewsonic CDE8630-E1 is an impressive 86-inch signage display designed to deliver superior visual performance in commercial and professional environments. With its Ultra HD 4K resolution, this display brings content to life with vivid clarity and dynamic color accuracy, making it ideal for digital signage in conference rooms, retail spaces, and educational institutions.
It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.
Screen Size
86 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
450 nits
Weight
43.2 kg
- 86-Inch 4K UHD Display
- High Brightness
- 24/7 Operation
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
86-Inch 4K UHD Display
Expansive screen with Ultra HD resolution ensures crisp, vibrant visuals.
02
High Brightness
Exceptional brightness for clear visibility in well-lit environments.
03
24/7 Operation
Engineered for continuous, reliable commercial use.
04
Integrated Media Player
Effortlessly schedule and play content without external devices.
05
Multiple Connectivity Options
Equipped with HDMI, USB, LAN, and wireless capabilities for versatile integration.
06
Remote Management
Manage and update content remotely for streamlined operation.
07
Slim Bezel Design
Modern, sleek appearance maximizes viewing area and aesthetics.
08
Wide Viewing Angles
Delivers consistent image quality from any viewing position.
Specifications
40 specificationsGeneral
Key FeaturesAll-in-one solution, Embedded Signage Platform, Integrated RJ45 and USB Wi-Fi, ViewBoard Cast content sharing, myViewBoard Display app, Remote management, AV control system interoperability, Tiling matrix, Landscape/Portrait mode
What's in the BoxWi-Fi adapter, Wall mount, Remote control with batteries, Quick start guide, Power cable, HDMI cable, USB-C cable, Screws, RS232 cable
Display
Aspect Ratio16:9
BacklightDirect LED
Bezel Size14.7 mm
Brightness450 nits
Color Depth10-bit (1.07 billion colours)
Contrast Ratio1,200:1 (typ.), 5,000:1 (DCR)
OrientationLandscape & Portrait
Panel TechnologyADS
Resolution3840 x 2160 (4K UHD)
Response Time8 ms
Screen Size86 inch
Viewing Angle178° (H) / 178° (V)
Performance
Operating SystemAndroid 11
ProcessorAmlogic T982
RAM4 GB
Storage32 GB
Audio
Audio OutSPDIF out × 1
Speaker Output2 × 10 W
Connectivity
BluetoothBuilt-in
EthernetRJ45 × 1
HDMI InputsHDMI In × 3
HDMI OutputsHDMI Out × 1
Input Voltage100–240 V AC
Serial PortRS-232 × 1
USB PortsUSB 3.0 × 1, USB 2.0 × 1
USB-C PortsUSB-C × 1
Wi-FiBuilt-in
Power
Power Consumption172 W (typical)
Standby Power≤ 0.5 W
Physical
Dimensions1930.8 x 1101.8 x 81.6 mm
Duty Cycle24/7
Operating Humidity10% to 90% RH
Operating Temperature0°C to 40°C
Shipping Dimensions2110 x 1227 x 225 mm
Surface ProtectionAnti-glare, 3H hardness, 25% haze
VESA Mount800 x 600 mm, M8 x 25 mm
Weight43.2 kg
Compliance
Warranty3 years (parts, labor and backlight)
Downloads
Manufacturer documents for the Viewsonic CDE8630-E1 - 86" Signage Display – CDE8630-E1 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What is the ViewSonic digital signage used for?
The Viewsonic CDE8630-E1 is an impressive 86-inch signage display designed to deliver superior visual performance in commercial and professional environments.
Does it include installation and warranty?
Procure.ae can arrange installation and provides manufacturer-backed warranty support. Contact us for the full warranty details applicable to this model.
What is this display used for?
It's a commercial digital signage display — ideal for menus, advertising, wayfinding, and information screens in retail, offices, and public spaces.
Can it run continuously for long hours?
Yes — commercial signage panels like this are built for extended daily operation; ask us for the exact operating-hours rating on this model.
How is the on-screen content managed?
