Viewsonic CDE8630 - 86" Display, 3840 x 2160 Resolution, 450 cd/m2 Brightness, 24/7 Signage Display – CDE8630

The Viewsonic CDE8630 - 86" Display, 3840 x 2160 Resolution, 450 cd/m2 Brightness, 24/7 Signage Display – CDE8630 is a digital signage available in the UAE from Procure.ae.

The Viewsonic CDE8630 is an impressive 86-inch 4K display designed for impactful visual presentations in commercial and professional environments. Boasting a stunning 3840 x 2160 resolution, this signage solution delivers ultra-sharp images and vibrant colors that captivate audiences. With a high 450 cd/m2 brightness level, the CDE8630 excels in both well-lit and dim environments, ensuring your content is always clear and visible.

It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.

Screen Size

86 inch

Resolution

3840 x 2160 (4K UHD)

Brightness

450 nits

Weight

43.2 kg

Key features

Ultra HD 4K Resolution

Experience exceptional image clarity with a 3840 x 2160 resolution for detailed visuals.

86-Inch Large Screen

Command attention and maximize impact with an expansive 86-inch display area.

450 cd/m2 Brightness

Enjoy vivid, clear images even in brightly lit environments.

24/7 Operation

Designed for continuous, round-the-clock performance in demanding commercial settings.

Versatile Connectivity

Connect easily with multiple inputs, including HDMI, USB, and LAN ports.

Commercial-Grade Durability

Built for reliable, long-term use with robust materials and components.

Sleek, Modern Design

Enhances any environment with its slim profile and professional appearance.

Integrated Media Player

Play content directly from USB drives for effortless presentations.

Specifications

General
Key Features	Multiple Ways To Connect And Share Content, AV Control System Interoperability, Centralized Control Device Management, Easy Content Sharing, Superb And Stunning Picture Quality, Powerful Secured Embedded Platform
What's in the Box	Remote control with batteries, Quick Start Guide, Power cable, HDMI Cable, USB-C cable, Wall Mount Screws, RS232 cable

Display
Aspect Ratio	16:9
Backlight	Direct LED
Bezel Size	14.7 mm
Brightness	450 nits
Color Depth	10-bit (1.07 billion colours)
Contrast Ratio	1,200:1 (typ.), 5,000:1 (DCR)
Orientation	Landscape & Portrait
Panel Technology	ADS
Resolution	3840 x 2160 (4K UHD)
Response Time	8 ms
Screen Size	86 inch
Viewing Angle	178° (H) / 178° (V)

Performance
Operating System	Android 11
Processor	Amlogic T982
RAM	4 GB
Storage	32 GB

Audio
Audio Out	SPDIF out × 1
Speaker Output	2 × 10 W

Connectivity
Ethernet	RJ45 × 1
HDMI Inputs	HDMI In × 3
HDMI Outputs	HDMI Out × 1
Input Voltage	100–240 V AC
OPS Slot	Yes (80-pin Intel OPS)
Serial Port	RS-232 × 1
USB Ports	USB 3.0 × 1, USB 2.0 × 1
USB-C Ports	USB-C × 1

Power
Power Consumption	172 W (typical)
Standby Power	≤ 0.5 W

Physical
Dimensions	1930.8 x 1101.8 x 81.6 mm
Operating Humidity	10% to 90% RH
Operating Temperature	0°C to 40°C
Shipping Dimensions	2110 x 1227 x 225 mm
Surface Protection	Anti-glare, 3H hardness, 25% haze
VESA Mount	800 x 600 mm
Weight	43.2 kg

Compliance
Warranty	3 years (parts, labor and backlight)
