ViewSonicDigital SignageSKU CDE5530-W1
Viewsonic CDE5530-W1 - 55" Signage Display – CDE5530-W1
The Viewsonic CDE5530-W1 - 55" Signage Display – CDE5530-W1 is a digital signage available in the UAE from Procure.ae.
Experience the power of dynamic visual communication with the Viewsonic CDE5530-W1 – a premium 55" signage display crafted for modern business environments. This feature-rich digital signage screen is engineered to deliver vibrant 4K UHD resolution, ensuring your content stands out with astonishing clarity. The Viewsonic CDE5530-W1 is ideal for commercial display applications in retail, hospitality, education, and corporate settings.
It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.
Screen Size
55 inch
Resolution
3840 x 2160 (4K UHD)
Brightness
450 nits
Weight
13.4 kg
- 55" 4K UHD Display
- Ultra-Slim Bezels
- 24/7 Reliability
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
55" 4K UHD Display
Offers ultra-high-definition visuals for crisp, detailed image quality.
02
Ultra-Slim Bezels
Modern, sleek design maximizes viewing area and lends a premium look.
03
24/7 Reliability
Engineered for continuous operation in demanding commercial environments.
04
Wireless Content Sharing
Effortlessly share and update content via Wi-Fi connectivity.
05
Remote Device Management
Easily control and schedule displays from any location.
06
Multiple Connectivity Options
HDMI, USB, and LAN inputs for versatile device integration.
07
Integrated Speakers
Built-in audio for impactful presentations without external equipment.
08
Energy-Efficient Performance
Reduces operational costs while maintaining high performance.
Specifications
40 specificationsGeneral
Key FeaturesAll-in-one solution includes ViewBoard display and Wi-Fi adapter, Powerful ViewSonic Embedded Signage Platform (VESP), Integrated RJ45 and USB Wi-Fi, ViewBoard Cast content sharing software, myViewBoard Display app for remote screen sharing
What's in the BoxCDE5530 Wireless Presentation Display, Wi-Fi adapter, Remote control with batteries, Quick Start Guide, Power cable, HDMI Cable, USB-C cable, Wall Mount, Screws and RS232 cable
Display
Aspect Ratio16:9
BacklightDirect LED
Bezel Size9.9 mm
Brightness450 nits
Color Depth10-bit (1.07 billion colours)
Contrast Ratio1,200:1 (typ.), 5,000:1 (DCR)
OrientationLandscape & Portrait
Panel TechnologyVA
Resolution3840 x 2160 (4K UHD)
Response Time6.5 ms
Screen Size55 inch
Viewing Angle178° (H) / 178° (V)
Performance
Operating SystemAndroid 11
ProcessorAmlogic T982
RAM4 GB
Storage32 GB
Audio
Audio OutSPDIF out × 1
Speaker Output2 × 10 W
Connectivity
BluetoothBuilt-in
EthernetRJ45 × 1
HDMI InputsHDMI In × 2
HDMI OutputsHDMI Out × 1
Input Voltage100–240 V AC
Serial PortRS-232 × 1
USB PortsUSB 3.0 × 1, USB 2.0 × 1
USB-C PortsUSB-C × 1
Wi-FiBuilt-in
Power
Power Consumption82 W (typical)
Standby Power≤ 0.5 W
Physical
Dimensions1233 x 703.5 x 71.5 mm
Duty Cycle24/7
Operating Humidity10% to 90% RH
Operating Temperature0°C to 40°C
Shipping Dimensions1332 x 819 x 156 mm
Surface ProtectionAnti-glare, 3H hardness, 25% haze
VESA Mount400 x 200 mm
Weight13.4 kg
Compliance
Warranty3 years (parts, labor and backlight)
Downloads
Manufacturer documents for the Viewsonic CDE5530-W1 - 55" Signage Display – CDE5530-W1 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What is the ViewSonic digital signage used for?
Experience the power of dynamic visual communication with the Viewsonic CDE5530-W1 – a premium 55" signage display crafted for modern business environments.
Does it include installation and warranty?
Procure.ae can arrange installation and provides manufacturer-backed warranty support. Contact us for the full warranty details applicable to this model.
What is this display used for?
It's a commercial digital signage display — ideal for menus, advertising, wayfinding, and information screens in retail, offices, and public spaces.
Can it run continuously for long hours?
Yes — commercial signage panels like this are built for extended daily operation; ask us for the exact operating-hours rating on this model.
How is the on-screen content managed?
