LG Ultra HD Large Display 75 Inch 75UH5PC(MEA)
- SKU: 75UH5PC(MEA)
Actual Stock Can Be Confirmed After Placing the Order.
OVERVIEW Ultra HD Resolution (3,840 x 2,160) Ultra HD Large screen delivers immersive viewing experience by 4 times higher defi nition picture quality than FHD. High Efficiency Video Coding Supports HEVC-based content which has the double data compression ratio than the H.264, so network... See More
OVERVIEW
Ultra HD Resolution (3,840 x 2,160)
Ultra HD Large screen delivers immersive viewing experience by 4 times higher defi nition picture quality than FHD.
High Efficiency Video Coding
Supports HEVC-based content which has the double data compression ratio than the H.264, so network traffi c can be reduced by half.
Multiple Screen
Multiple Screen with PBP or PIP
PBP (Picture-By-Picture) and PIP (Picture-In-Picture) feature gives a chance to compose up to 4 divided split screen on landscape or portrait display format.
Quad Core SoC*
The High Performance SoC can execute several tasks at the same time and provides smooth content playback.
webOS 2.0
The webOS 2.0 platform provides powerful and convenient tools to create, including app development materials.
BEACON
With BEACON and Bluetooth Low Energy (BLE) supported by 75UH5PC, retail stores can provide coupons and information in real-time.
OPS* Kit / HDBaseT Box
The 75UH5PC provides an OPS Kit to connect a third-party OPS player or HDBaseT box. Users have the flexibility to choose any media player as long as it complies with the OPS.
Real-Time Remote Monitoring
When an alarm occurs, an e-mail notifi cation is sent using SuperSign C or SI SW through the SNMP Protocol. In case of malfunctions or errors, real-time remote care is available.
SPECIFICATIONS
| Screen Size | 75" |
|---|---|
| Resolution | 3,840 x 2,160 (UHD) |
| Brightness (Typ., cd/m²) | 500 |
| Input | HDMI (3), DP, DVI-D, Audio, USB 3.0, SD Card |
|---|---|
| Output | DP, Audio |
| External Control | RS232C, RJ45, IR Receiver, Pixel Sensor |
| Bezel Width | 14.9 mm (Off-bezel) |
|---|---|
| Monitor Dimension (W x H x D) | 1,682.4 x 963.3 x 59.5 mm (Without Handle, with LG logo) |
| Weight (Head) | 41.5kg |
| Operation Temperature | 0°C to 40°C |
|---|---|
| Operation Humidity | 10 % to 80 % |
| Typ. | 160 W |
|---|---|
| Smart Energy Saving | 120 W |
| Safety | UL / cUL / CB / TUV / KC |
|---|---|
| EMC | FCC Class "A" / CE / KCC |
| ErP / Energy Star | No / Energy Star 7.0 |
| OPS type compatible | Yes |
|---|---|
| External Media player Attatchable | Yes (MP500/MP700) |
| Content Management Software | SuperSign W |
|---|---|
| Control and Monitoring Software | SuperSign C |
| Basic | Remote Controller (include 2ea batteries), Power Cord, QSG, DP 1.8M, Regulation Book, Phone to RS232C Gender, Memory Cover |
|---|---|
| Optional | Pixel Sensor (KT-SP0), Media Player, OPS Kit (KT-OPSA), HDBaseT (EB-B100), LSW640A/B (Wall Mount) |
No datasheet available.
