Philips Signage Solutions Glasses free 3D Display 55" BDL5571VS/00
- SKU: BDL5571VS/00
Actual Stock & Price Can Be Confirmed After Placing the Order.
Overview Autostereoscopic 3D Enjoy a stunning 3D experience with no need for special glasses thanks to the autostereoscopic 3D effect. Using lenticular technology, it gives excellent clarity and depth, making your 3D experience even more lifelike and enjoyable. 3D content visualization Software tools are... See More
Overview
-
Autostereoscopic 3D
Enjoy a stunning 3D experience with no need for special glasses thanks to the autostereoscopic 3D effect. Using lenticular technology, it gives excellent clarity and depth, making your 3D experience even more lifelike and enjoyable.
-
3D content visualization
Software tools are provided with the display to play-out 3D content and control the 3D and 2D visualization parameters. The actual 3D content can be created via plug-ins available for popular 3D animation software packages. Existing 2D or stereo content can be converted into 2D-plus-Depth format. The 2D-plus-Depth format is compatible with existing compression tools, as the additional bandwidth of the depth is small.
-
3D & 2D dual mode display
The display can be applied in a broad range of applications since it can be operated in in both 2D and 3D mode. The 4K UHD resolution panel enables great picture quality and true color representation in 2D and 3D mode. The integrated rendering core offers content creators and end-users full control over the quality and depth-effect characteristics of the picture.
-
3D system solution
The system solution is designed for maximum reuse of content / concepts from the 2D signage industry. The key enabler for this is the flexible 2D-plus-Depth format that allows decoupling of content creation and content visualization. The rendering core integrated in the autostereoscopic 3D displays supports the unique Declipse image format which enables a true look-around 3D effect.
-
Display Port for faster graphics support
Enjoy crystal clear images with the high-bandwidth graphics support of the Display Port. As well as transmitting full high-definition video the Display Port will also transmit audio, thus eliminating the need for extra cables.
-
Module for DVI out capabilities
Create a digital video wall of up to 9 displays in a 3 x 3 configuration with the optional DVI module. Simply slide the module in to the open slot on the side of the display, then connect the DVI out port to a DVI in of another display to create the most stunning video wall experience around.
-
120 Hz Panel
Enjoy stunningly clear video images thanks to the 120 Hz panel. Even fast moving action scenes can be seen with no blur, enhancing your viewing experience.
-
Smart insert in the backcover to place a small pc
Professional PC's are part of most public signage installations. Quite often they increase the overall depth to the display and cause a lot of cable clutter. So we have designed this display with Smart insert in the back cover which is ideal for the integration of a professional small form factor PC. On top of that, the cable management system offers a great solution to keep your cables neat and professional looking.
-
Many Functions. One Wire
Take full control of your display by running all operational commands as well as your video signal through just one single HDMI cable. This unique feature makes it so much easier and more convenient to ensure the smooth running and maintenance of your display. Consumer Electronics Control (CEC) commands make finding out vital information about your display absolute childsplay.
-
Network Controllability: RJ45
Simple management of your display is available thanks to the introduction of a LAN (RJ45) port. You can configure each display or find out the status of each device quickly and conveniently via an RJ45 connection.
-
Slim bezel design for a stylish look
A slim bezel design adds a stylish look to a public display to nicely blend in just about any environment. Furthermore this design makes the display ideal for tiled matrix video walls.
-
Full HD LCD display, 1920x1080p
This display has a resolution that is referred to as Full HD. The state-of-the-art LCD screen technology has the full high-definition widescreen resolution of 1080 progressive lines, each with 1920 pixels. This allows the best possible picture quality for HD input signals with up to 1080 lines. It produces brilliant flicker-free progressive scan pictures with optimum brightness and superb colors. This vibrant and sharp image will provide you with an enhanced viewing experience.
Specifications
Model | BDL5571VS/00 | BDL2331VS/00 |
---|---|---|
3D Technology |
|
|
Aspect ratio |
16:9
|
16:9
|
Brightness |
700 cd/m²
|
300 cd/m²
|
Contrast ratio (typical) |
1300:1
|
1000:1
|
Diagonal screen size (inch) |
55 inch
|
23 inch
|
Diagonal screen size (metric) |
140 cm
|
58.9 cm
|
Display colors |
1.06 Billion colors
|
16.7 million colors
|
Display technology |
120 Hz Panel
|
No
|
Optimum resolution |
1920 x 1080 @ 60Hz
|
1920 x 1080 @ 60Hz
|
Panel resolution |
1920x1080p
|
1920x1080p
|
Picture enhancement |
|
|
Pixel pitch |
0.63 x 0.63 mm
|
0.265 x 0.265 mm
|
Response time (typical) |
10 ms
|
5 ms
|
Viewing angle (horizontal) |
150 degree
|
150 degree
|
Viewing angle (vertical) |
150 degree
|
150 degree
|
Packaging dimensions
BDL5571VS/00 | BDL2331VS/00 | |
---|---|---|
Depth |
30 cm
|
No
|
EAN |
87 12581 62642 6
|
No
|
Gross weight |
42.3 kg
|
No
|
Height |
105 cm
|
No
|
Nett weight |
38.7 kg
|
No
|
Number of products included |
1
|
No
|
Packaging type |
Carton
|
No
|
Tare weight |
3.6 kg
|
No
|
Width |
167 cm
|
No
|
Product dimensions
BDL5571VS/00 | BDL2331VS/00 | |
---|---|---|
Depth |
12.3 cm
|
No
|
Depth (with stand) |
42.3 cm
|
No
|
Height |
72.29 cm
|
No
|
Height (with stand) |
102.2 cm
|
No
|
Weight |
26.4 kg
|
No
|
Weight (with stand) |
55.5 kg
|
No
|
Width |
125 cm
|
No
|
Connectivity
BDL5571VS/00 | BDL2331VS/00 | |
---|---|---|
AV input |
|
No
|
AV output |
Audio (L/R) x1
|
Audio (L/R) x1
|
Other connections |
|
No
|
PC |
|
DVI-D x1
|
USB |
No
|
USB 2.0 x 1
|
Convenience
BDL5571VS/00 | BDL2331VS/00 | |
---|---|---|
Ease of installation |
|
No
|
Energy saving functions |
|
|
Keyboard control |
|
|
Network controllable |
|
No
|
Packaging |
Reusable box
|
Reusable box
|
Picture in picture |
|
No
|
Picture performance |
Advanced color control
|
Advanced color control
|
Placement |
Landscape
|
Landscape
|
Remote control signal |
Lockable
|
No
|
Safety control functions |
|
|
Screen saving functions |
Pixel shift, Low bright
|
Pixel shift, Low bright
|
Signal Loop Through |
|
No
|
Dimensions
BDL5571VS/00 | BDL2331VS/00 | |
---|---|---|
Bezel thickness |
19.5mm/0.8"
|
1.6 cm / 0.63 inch
|
Product weight |
80 kg
|
6.5 kg
|
Product weight (lb) |
176
|
14.3
|
Set Depth |
121.8 mm
|
50 mm
|
Set Depth (inch) |
4.8 inch
|
No
|
Set depth (with stand) |
405.1 mm
|
171 mm
|
Set depth (with stand) (inch) |
15.95 inch
|
No
|
Set Height |
722.9 mm
|
360 mm
|
Set Height (inch) |
28.5 inch
|
No
|
Set height (with stand) |
773.2 mm
|
499 mm
|
Set height (with stand) (inch) |
30.4 inch
|
No
|
Set Width |
1252.1 mm
|
566 mm
|
Set Width (inch) |
49.3 inch
|
No
|
Smart insert in inch (WxHxD) |
11.81 x 11.89 x 2.52
|
No
|
Smart Insert mount |
300 x 320 x 64
|
No
|
VESA Mount |
400x400mm (Set), 100x100mm (Smart insert)
|
100 x 100 mm
|
Operating conditions
BDL5571VS/00 | BDL2331VS/00 | |
---|---|---|
MTBF |
60,000 hour(s)
|
50.000 hour(s)
|
Relative humidity |
5 - 90 %
|
20 - 80 %
|
Temperature range (operation) |
0 - 40 °C
|
0 - 40 °C
|
Power
BDL5571VS/00 | BDL2331VS/00 | |
---|---|---|
Consumption (On mode) |
Typ. 214W
|
Typ. 28.62W
|
Standby power consumption |
< 1W (One Wire and RS232 active)
|
0.1W
|
Sound
BDL5571VS/00 | BDL2331VS/00 | |
---|---|---|
Built-in speakers |
2 x 12 W (8 ohm)
|
2 x 1.5 W
|
Accessories
BDL5571VS/00 | BDL2331VS/00 | |
---|---|---|
Included accessories |
|
|
Optional accessories |
No
|
3D rendering box
|
Miscellaneous
BDL5571VS/00 | BDL2331VS/00 | |
---|---|---|
On-Screen Display Languages |
|
|
Regulatory approvals |
|
|
Warranty |
Europe/North America: 1 year
|
Europe/North America: 1 year
|
