Weight & dimensions
|
Height 1141 mm |
|
Width 1949 mm |
|
Depth 92 mm |
|
Weight 84 kg |
|
Audio
|
Number of speakers 2 |
|
Built-in speaker(s) Si |
|
RMS rated power 20 W |
|
Display
|
Display type LED |
|
Response time 12 ms |
|
Display resolution 3840 x 2160 Pixel |
|
Touch screen No |
|
Display diagonal 2.13 m 84 |
|
Display brightness 500 cdm² |
|
HD type 4K Ultra HD |
|
Contrast ratio (typical) 14001 |
|
Native aspect ratio 169 |
|
Active display area (W x H) 1860 x 1047 mm |
|
Horizontal scan range 15.73 - 135 kHz |
|
Viewing angle, horizontal 178° |
|
Viewing angle, vertical 178° |
|
Display diagonal (metric) 213.46 cm |
|
Supported graphics resolutions 640 x 480 VGA, 800 x 600 SVGA, 1024 x 768 XGA, 1280 x 1024 SXGA, 1280 x 768 WXGA, 1366 ? 768, 1600 x 900, 1920 x 1080 HD 1080, 1920 x 1200 WUXGA, 3840 x 2160 |
|
Supported video modes 480i,480p,576i,576p,720p,1080i,1080p,2160p |
|
Contrast ratio (dynamic) 5000001 |
|
Vertical scan range 59.94 - 60 Hz |
|
Design
|
Colour of product Nero, Metallico |
|
Design Digital signage flat panel |
|
Packaging data
|
Manual Si |
|
Package width 2156 mm |
|
Package depth 404 mm |
|
Package height 1361 mm |
|
Package weight 106 kg |
|
Cables included AC |
|
Power
|
AC input voltage 220 - 240 |
|
AC input frequency 5060 |
|
Power consumption (typical) 540 W |
|
Power consumption (off) 0.3 W |
|
Power consumption (standby) 0.5 W |
|
Operational conditions
|
Operating temperature (T-T) 0 - 40 °C |
|
Storage relative humidity (H-H) 20 - 80 |
|
Operating altitude 0 - 2400 m |
|
Operating relative humidity (H-H) 20 - 80 |
|
Storage temperature (T-T) -20 - 60 °C |
|
Performance
|
HDCP Si |
|
TV tuner integrated No |
|
Multi-display supported Si |
|
Panel life 50000 h |
|
Ports & interfaces
|
HDMI ports quantity 4 |
|
DVI-D ports quantity 1 |
|
USB port No |
|
Ethernet LAN Si |
|
Ethernet LAN (RJ-45) ports 1 |
|
RS-232C Si |
|
DVI port Si |
|
Audio (L,R) in 2 |
|
Ethernet LAN data rates 10.100 Mbits |
|
HDMI in 4 |
|
VGA (D-Sub) input ports 1 |
|
