LG Full HD Large Display 55 Inch 55LS73D
- SKU: 55LS73D
Actual Stock Can Be Confirmed After Placing the Order.
OVERVIEW Quad Core SoC* The high-performance SoC can execute several tasks at the same time and provides smooth content playback. webOS 3.0 The webOS 3.0 platform provides powerful and convenient creation tools, including app development materials. Group Manager Content can be created, distributed and... See More
OVERVIEW
Quad Core SoC*
The high-performance SoC can execute several tasks at the same time and provides smooth content playback.
webOS 3.0
The webOS 3.0 platform provides powerful and convenient creation tools, including app development materials.
Group Manager
Content can be created, distributed and controlled by a signage without a dedicated PC or server.
PBP (Picture-By-Picture) / PIP (Picture-In-Picture)
PBP (Picture-By-Picture) and PIP (Picture-In-Picture) features enable you to compose various layouts for several digital devices.
IP Streaming Protocol
Various types of IP video streaming protocol are supported, such as RTSP/RTP, MMS, HLS and
MPEG-2 TS*.
Secure Communication Protocol
By supporting HTTPS* protocol, communication between server and signage is more secure.
Proxy Server
Web access speed and security can be improved by supporting Proxy Server (A server that acts as an intermediary for requests from clients seeking resources from other servers.)
Mirroring
Content sharing is more convenient on a Wi-Fi network.
Soft AP
The 55LS73D with Soft AP software can operate as a wireless access point for mobile devices.
Simple Installation
Installation has been simplified by removing the external media player and Ethernet/
RS232C cables.
Becon
With Beacon and Bluetooth Low Energy (BLE) supported by 55LS73D*,
retail stores can provide coupons and information in real time.
Enhanced Maintenance
Dust & Humidity Protection
Circuit board reliability is enhanced with conformal coating that protects against dust, iron powder, humidity and other harsh conditions.
Detachable logo
The detachable logo allows for installation in the desired orientation and scape or portrait mode.
SPECIFICATIONS
| Screen Size | 55" |
|---|---|
| Resolution | 1,920 x 1,080 (FHD) |
| Brightness(cd/㎡) | 500 |
| Input | HDMI (2), DP, DVI-D, Audio In, OPS, USB 3.0 |
|---|---|
| Output | DP, External Speaker Out |
| External Control | RS232C in/out, RJ45, IR / Light Sensor, Pixel Sensor |
| Bezel Width | 7.4 mm (T/L/R/B even) |
|---|---|
| Monitor Dimension (W x H x D) | 1,230 x 714 x 32 mm |
| Weight (Head) | 20.7 kg |
| VESA™ Standard Mount Interface | 400 x 400 |
| Operation Temperature | 0°C to 40°C |
|---|---|
| Operation Humidity | 10 % to 80 % |
| Power Supply | 100-240 V~, 50/60 Hz |
|---|---|
| Power Type | Built-In Power |
| Typ. | 120W |
|---|---|
| Smart Energy Saving | 85W |
| Safety | UL / cUL / CB / TUV / KC |
|---|---|
| EMC | FCC Class "A" / CE / KCC |
| ErP / Energy Star | NA / Yes (Energy Star 7.0) |
| OPS type compatible | Yes |
|---|---|
| External Media player Attatchable | Yes (MP500/MP700) |
| Content Management Software | SuperSign Premium |
|---|---|
| Control and Monitoring Software | SuperSign C |
| Basic | Remote Controller (2ea batteries included), Power Cord, IR / Light Sensor Receiver, QSG, Regular Book (depend on regional standard), HDMI Cable |
|---|---|
| Optional | External Speaker (SP-2100), Stand(ST-200T), Wall Mount(LSW440S), Wi-Fi USB Dongle (AN-WF500), OPS Kits (KT-OPSA), Pixel Sensor (KT-SP0) |
