Overview

Installs and grounds in less than 5 minutes

Save time with quick and easy installation with the CV Series – 5 minutes or less.

• One technician
• One hole with standard Greenlee® punch
• Panel door does not need to be removed
• Grounds instantly to metal enclosure with patent-pending AutoGround™ process
• Maintains panel arc test ratings up to 63kA when properly installed

Work more efficiently with Fluke ClirVu® CV300 75 mm (3 in) Infrared Windows

• NFPA 70E processes significantly reduced due to less work permit requirements
• Faster and more comfortable inspections because full PPE is often not required
• Reduce the risk of arc-flash and electrocution, increase the safety of your personnel and reduce the time and cost of preventive maintenance
• CV300 is Torture Tested™ to the highest arc blast test ratings IEEE C37.20.7: 63 kA Arc tested at KEMA, UL 50/50E/50V, UL1558, IEC60529-1: IP67, IEC 60068, NEMA 4/12, CSA C22.2 NO. 14-13:2012, and CE
• Convenience of both quick turn or security keyed access
