BSS Soundweb London BLU-6 Wall-Mount Controller
The BSS Audio Soundweb London BLU-6 Programmable Wall Controller provides 6 programmable buttons and a backlit LCD display for intuitive end-user control of BSS Soundweb audio systems in meeting rooms and commercial spaces across the UAE.
The BSS Audio Soundweb London BLU-6 is a wall-mount Ethernet controller panel designed for user-facing control of Soundweb London installed sound systems. Its 6 programmable buttons can be configured in Audio Architect to trigger any Soundweb parameter — source selection, preset recalls, zone enables, volume steps, or mute toggles — while the backlit LCD display provides contextual labeling of each button's current function. Unlike the simpler EC-4BV and EC-V panels, the BLU-6 includes a display screen, giving end users clear visual feedback on system state without requiring knowledge of the underlying DSP configuration. The unit connects via a single Ethernet cable and is powered by PoE from the network switch.
It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.
Weight
0.5 kg
- 6 Programmable Ethernet Buttons
- Backlit LCD Display
- Single Ethernet Connection
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
6 Programmable Ethernet Buttons
Each button configurable in Audio Architect for any Soundweb London parameter or system action.
02
Backlit LCD Display
Dynamic label display for each button showing current function, state, and system status to end users.
03
Single Ethernet Connection
Connects to the Soundweb London processor via standard Cat5e/6 network infrastructure.
04
PoE Powered
Draws power from a compatible PoE network switch — no separate power adapter or low-voltage wiring required.
05
Audio Architect Software Configuration
All button parameters, labels, and display content configurable via the free BSS Audio Architect software.
06
Single-Gang Wall-Mount Format
Installs in a standard single-gang wall box for clean, professional room integration.
07
LED Button Status Indicators
Per-button LEDs provide immediate visual feedback on active states and selections.
08
Soundweb London System Compatible
Works with all BSS Soundweb London processor family devices.
Specifications
10 specificationsGeneral
CompatibilityBSS Soundweb London Processors
Connectivity
ConnectivityEthernet, RS-232, RS-485, GPIO, USB
Power
Power SourcePoE (Power over Ethernet) or External Power Supply (12 V DC)
Physical
ColorBlack
Dimensions175 x 119 x 36 mm
Form FactorWall-mount
MountingWall mount, tabletop stand (sold separately)
Weight0.5 kg
Compliance
Country of OriginUnited Kingdom
Warranty1 year
Questions
Can’t find your answer? Ask on WhatsApp
How does the BSS BLU-6 compare to the EC-4BV controller?
The BLU-6 adds a backlit LCD display to the programmable button format, allowing contextual labeling of each button's function — users can see what each button does without referring to a separate label plate. The EC-4BV has no display but is smaller and lower-cost. Choose the BLU-6 for rooms where end-user clarity and display feedback are important; choose the EC-4BV for simpler, cost-sensitive installations.
