AISPEECHMeeting Room SolutionsSKU MC04
AISPEECH Compact Educational Ceiling Microphone – MC04
The AISPEECH MC04 is a compact ceiling microphone for standard classrooms and compact teaching spaces. It uses a 24-element MEMS array with a recommended 3.5 m pickup radius and runs on PoE+. It also supports sound reinforcement and up to two cascaded units. Procure.ae supplies the AISPEECH MC04 across the UAE.
The MC04 captures a teacher's voice with a 24-element MEMS array and a 48 kHz sample rate. The manufacturer recommends a 3.5 m pickup radius and a 2 m reinforcement radius. Noise suppression is rated at 35 dB, and the signal-to-noise ratio is 73.9 dBA. Analog connections use four Phoenix analog inputs and two Phoenix analog outputs, and the network port is a 10/100/1000M RJ-45 PoE connection.
The MC04 is designed for standard classrooms and compact teaching spaces. It installs on the ceiling with a discreet, low-profile design, and up to two units can be cascaded. Its operating temperature is 0 to 40 °C and its power consumption is 12 W. Compared with the larger MC08 and MC10 ceiling microphones, the MC04 is a smaller 270 x 270 mm unit aimed at classroom use.
Type
Ceiling Microphone
Weight
< 2 kg
- 24-element array
- Recommended pickup radius
- Noise suppression
Delivery across UAE & GCCDubai, Abu Dhabi, Sharjah & beyond
Manufacturer warrantyBacked by the brand
InstallationArranged on request
Key features
01
24-element array
Compact MEMS array for clear voice capture in classrooms.
02
Recommended pickup radius
3.5 m recommended pickup radius and 2 m reinforcement radius.
03
Noise suppression
35 dB noise suppression and 73.9 dBA signal-to-noise ratio.
04
Analog I/O
Four analog inputs and two analog outputs on Phoenix terminals.
05
PoE+ network
One 10/100/1000M RJ-45 PoE port, 12 W power consumption.
06
Cascade support
Up to two units can be cascaded.
07
Low-profile ceiling mount
270 x 270 x 54.75 mm unit for ceiling installation.
Specifications
18 specificationsGeneral
Key Features24-element MEMS array, 48 kHz sample rate, 35 dB noise suppression, 2 m recommended reinforcement radius, 3.5 m recommended pickup radius, cascade up to 2 units
ModelMC04
TypeCeiling Microphone
Performance
Storage Conditions-20 to +70 °C
Audio
Microphone Type24-element MEMS array
Pickup Range3.5 m recommended pickup radius
Signal-to-Noise Ratio73.9 dBA
Connectivity
Inputs4 analog
Outputs2 analog
PoEPoE+
PortsRJ-45 10/100/1000M PoE × 1, Analog In × 4 (Phoenix), Analog Out × 2 (Phoenix)
Power
Power Consumption12 W
Physical
ColorWhite
Dimensions270 x 270 x 54.75 mm
MountingCeiling mount
Operating Humidity20% to 95% RH
Operating Temperature0 to 40 °C
Weight< 2 kg
Downloads
Manufacturer documents for the AISPEECH Compact Educational Ceiling Microphone – MC04 — datasheets, manuals, drawings and certificates.
Questions
Can’t find your answer? Ask on WhatsApp
What is the AISPEECH MC04?
The AISPEECH MC04 is a compact educational ceiling microphone for standard classrooms and compact teaching spaces. It captures the teacher's voice with a 24-element MEMS array and supports sound reinforcement for classroom audio upgrades.
What pickup range does the MC04 cover?
The manufacturer recommends a 3.5 m pickup radius and a 2 m reinforcement radius for the MC04. The unit uses a 24-element MEMS array with a 48 kHz sample rate and 35 dB noise suppression.
Can the MC04 be installed on a classroom ceiling?
Yes. The MC04 is designed for ceiling mounting, and its size is 270 x 270 x 54.75 mm. It is powered over PoE+ through its RJ-45 port, which carries both power and the network connection.
Can MC04 units be cascaded?
Yes. The manufacturer states that up to two MC04 units can be cascaded. The unit has four Phoenix analog inputs and two Phoenix analog outputs for analog connections. Its operating temperature range is 0 to 40 °C.
