ViewSonic CDE Series 75-inch 4K Digital Signage Display – CDE7514-2C
The ViewSonic CDE7514-2C is a 75-inch 4K UHD commercial display for corporate, retail, transit and digital signage environments. It offers 500 nits brightness, 1,500:1 typical contrast and Android 14 with Pro AV integration. Procure.ae supplies the ViewSonic CDE7514-2C in the UAE.
The CDE7514-2C has a 3840 x 2160 native panel with 1,500:1 typical contrast, rising to 2,000:1 with DCR enabled. Its 11 ms response time and 178-degree horizontal and vertical viewing angles are part of the manufacturer's specifications. An anti-glare surface with 3H hardness and 25% haze is listed among its features. A quad-core ARM Cortex-A73 processor with 4 GB RAM and 32 GB storage runs Android 14, and continuous USB media playback continues through auto signal failover.
The manufacturer describes the display as built for 24/7 operation in offices, retail spaces and transit hubs. It integrates with leading Pro AV control systems and ViewSonic Manager, and its RS-232 port, RJ45 connection and USB-C input with DisplayPort 1.2 support AV and IT setups. The 600 x 400 mm VESA pattern supports wall mounting. The set measures 1685.6 x 963.7 x 68 mm, with a net weight of 34.15 kg.
Key features
Specifications
| Key Features | Auto signal failover for USB media, ViewSonic Launcher, ViewSonic Manager remote control, AirSync wireless presentation, Landscape and portrait, Pro AV control integration |
| Model | CDE7514-2C |
| Type | Digital Signage Display |
| Aspect Ratio | 16:9 |
| Backlight | DLED |
| Bezel Size | 15.9 mm (all sides) |
| Brightness | 500 nits |
| Contrast Ratio | 1,500:1 (typical); 2,000:1 (DCR) |
| Orientation | Landscape and portrait |
| Panel Technology | LCD |
| Resolution | 3840 x 2160 (4K UHD) |
| Response Time | 11 ms |
| Screen Size | 75 inch |
| Viewing Angle | 178° horizontal, 178° vertical |
| Operating System | Android 14 |
| Processor | Quad-core ARM Cortex-A73 |
| RAM | 4 GB |
| Storage | 32 GB |
| Ethernet | RJ45 × 1 (10/100M, shared via USB-C) |
| Input Voltage | 100–240 V AC ±10% |
| Ports | RS-232 × 1, SPDIF × 1, RJ45 × 1, USB 2.0 × 2, USB-C × 1 |
| Serial Port | RS-232 × 1 |
| USB-C Ports | USB-C × 1 (DP 1.2, USB 2.0, 15 W PD, Ethernet sharing) |
| Wi-Fi | WiFi slot × 1 |
| Power Consumption | 93.89 W |
| Dimensions | 1685.6 x 963.7 x 68 mm |
| Operating Humidity | 20% to 80% RH, non-condensing |
| Operating Temperature | 0 to 40 °C |
| VESA Mount | 600 x 400 mm |
| Weight | 34.15 kg |
