Peerless SmartMount Back-to-Back Video Wall Pedestal Mount 2x2 – DS-S560-B2X2

The Peerless DS-S560-B2X2 is a back-to-back modular video wall pedestal mount for four displays sized 46 to 60 inches. It supports VESA patterns from 200 x 200 to 600 x 400 mm, carries up to 362.87 kg, and bolts directly to concrete. Procure.ae supplies it across the UAE.

The back-to-back 2x2 configuration arranges four displays on one pedestal, with a rated load capacity of 362.87 kg and a load capacity of 45.36 kg per display. Tool-less micro-adjustment at eight points aligns the screens, and quick-connect adaptors latch onto the mounting rails automatically. Each display attaches through VESA patterns from 200 x 200 mm up to 600 x 400 mm. The aluminium frame reduces overall weight, while a rear media storage shelf and cover keep components out of sight and rear brackets organise the cabling.

It is listed for digital signage, display screens and video walls, and it suits retail, public transportation and other high-traffic locations. It bolts directly to concrete, so no additional wall or ceiling supports are needed. The package includes display adaptors and hardware, and assembly is required. Compared with the DS-S560-2X2, this model is designed for back-to-back installation and carries 362.87 kg rather than 226.80 kg.
