Newline 86" Lyra Pro Interactive Display

The Newline 86" Lyra Pro Interactive Display is a interactive flat panel available in the UAE from Procure.ae.

The Newline 86" Lyra Pro Interactive Display offers an immersive, ultra-large touchscreen solution designed for modern classrooms and collaborative business environments. With its expansive 4K Ultra HD resolution , this advanced interactive flat panel delivers vibrant visuals and responsive touch technology for seamless presentations and creative brainstorming sessions. The Lyra Pro series is engineered for effortless connectivity, supporting multiple devices and wireless casting to enhance team collaboration . Its built-in annotation tools and intuitive user interface make it easy to engage.

It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.

Screen Size

86 inch

Resolution

3840 x 2160 (4K UHD)

Brightness

450 nits

Touch Technology

Stellar Touch Technology

Weight

65 kg

Key features

Ultra-Large 86" Display

Provides a commanding presence, perfect for large meeting rooms and classrooms.

4K Ultra HD Resolution

Delivers crisp, vibrant visuals for detailed presentations and rich multimedia content.

Multi-Touch Technology

Supports up to 20 simultaneous touch points for collaborative interaction.

Android-Based System

Ensures smooth performance and access to a wide range of educational and business apps.

Wireless Screen Sharing

Seamlessly connects laptops, tablets, and smartphones for effortless content sharing.

Integrated Annotation Tools

Enables real-time annotation and note-taking directly on the display.

Anti-Glare Tempered Glass

Reduces reflections and enhances screen durability for a better viewing experience.

Powerful Built-In Speakers

Provides clear, room-filling audio without the need for external equipment.

Specifications

General
Key Features	Palm rejection

Display
Backlight	Direct LED
Blue Light Filter	Yes
Brightness	450 nits
Color Depth	10-bit (1.07 billion colours)
Resolution	3840 x 2160 (4K UHD)
Screen Size	86 inch
Touch Accuracy	±1 mm
Touch Points	50-point multi-touch
Touch Response Time	< 5 ms
Touch Technology	Stellar Touch Technology
Viewing Angle	178° (H) / 178° (V)

Performance
Operating System	Android 13
Processor	Amlogic A311D2
RAM	8 GB
Storage	128 GB

Audio
Audio In	Mic in × 1
Audio Out	Line out × 1
DisplayPort	DisplayPort 1.2 In × 1
Speaker Output	2 × 20 W
Speaker Type	Built-in

Connectivity
Bluetooth	Bluetooth 5.2
Ethernet	RJ45 (Gigabit) × 2
HDMI Inputs	HDMI In (HDMI 2.1) × 2
HDMI Outputs	HDMI Out (HDMI 2.0) × 1
OPS Slot	Optional
Serial Port	RS-232 × 1
Touch USB Ports	Touch USB × 4
USB Ports	USB-A 3.2 × 4, USB-A 3.2 × 1 (to Android)
USB-C Ports	USB-C (65 W charging (Front), 15 W charging (Rear))
Wi-Fi	Wi-Fi 6 (802.11ax)

Power
Power Consumption	144 W
Standby Power	< 0.5 W

Physical
Dimensions	1982 x 1191 x 119 mm
Surface Protection	Anti-glare, anti-fingerprint, antimicrobial tempered glass
VESA Mount	800 x 400 mm
Weight	65 kg
