OVERVIEW
The UM330Xi-WK interactive projector brings collaboration to both classrooms and conference rooms alike. Together with a PC or Mac, the teaching tool will increase students’ attention and interaction within the classroom, increasing their retention of subject matter. This bundle includes the 3300-lumen UM330X ultra short throw projector, NP02Wi interactive eBeam module and stylus pen, and NP04WK1 wall mount kit. The UM330Xi-WK delivers an extremely short throw distance, and the interactive eBeam module attaches directly to the front of the projector and uses IR to determine the pen’s position within the image for accurate control and annotation. The UM330X is able to mount on the wall directly above the screen using the NP04WK1. Features of the projector include a powerful 16W speaker, closed captioning, RJ-45, wireless LAN (optional), dual HDMI, VGA and a microphone input to amplify the presenter’s voice.
SPECIFICATIONS
| Display Technology |
0.63" LCD w/ MLA |
|
| Light Output(Lumens) |
3300 lumens |
|
| Resolution |
|
| Native |
XGA 1024 x 768 |
|
| Maximum |
UXGA 1600 x 1200 |
|
|
|
| Contrast Ratio (up to) |
3000:1 |
|
| Lamp Type |
265W AC |
|
| Lamp Life (up to) |
3000 hours normal / 6000 hours eco |
|
| Screen Size (diagonal) |
61.5 to 116.6 in. / 1.6 to 2.96m |
|
| Throw Ratio |
0.36 to 1 |
|
| Projection Distance |
1.47 to 2.8 ft. / 0.45 to 0.85m |
|
| Projector Angle |
53.1° |
|
Lens
|
|
| Zoom |
1 to 1.4 |
|
| Focus |
Manual |
|
| F number, fnumber |
F=1.8 |
|
|
|
| Keystone Correction |
Automatic or manual +/- 10° |
|
| |
| |
| Synchronization Range |
|
| Horizontal (Analog/Digital) |
15-100 kHz |
|
| Vertical (Analog/Digital) |
50-120 Hz |
|
|
|
| Supported Video Standards |
NTSC, NTSC4.43, PAL, PAL-M, PAL-N, PAL 60, SECAM |
|
| SD/HD Video Signal Compatibility |
480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
|
| PC Signal Compatibility |
VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA |
|
| Macintosh Compatibility |
Yes |
|
| Input/Output Terminals |
|
| RGB1(analog) |
VGA 15-pin D-sub, Component video using ADP-CV 1E |
|
| RGB3(digital) |
HDMI |
|
| Video 1 |
RCA |
|
| Video 2 |
S-Video |
|
| Audio 1 |
1/8 in. stereo |
|
| Monitor out |
VGA 15-pin D-sub |
|
| Audio out |
Yes (variable) |
|
|
|
| Audio |
16W speaker |
|
| External Control |
RS-232, IR, Wired LAN, DDC/CI, USB, Wireless LAN (optional) |
|
| Sync Compatiblity |
Separate Sync / Composite Sync / Sync on G |
|
| Networking |
RJ-45 Monitoring |
|
| |
| |
| Power Requirements |
100-240V AC, 50/60 Hz |
|
| Input Current |
4.0A/2.0A |
|
| Power Consumption (Normal/ECO Mode/Standby/Standby Power Saving) |
344W / 233W / 8W / 0.2W |
|
| |
| |
| Installation Orientation |
Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear |
|
| Dimensions (WxDxH) |
26 x 22 x 20 in. / 660 x 559 x 508mm |
|
| Net Weight |
49 lbs. / 22.2 kg |
|
| Fan Noise |
35 dB normal / 28 dB eco |
|
| Regulations |
USA UL 60950-1 FCC Class B, C-UL CSA 60950-1 ICES-003 Class B |
|
|
| |
| Operating Temperature |
41-104°F / 5-40°C |
|
| Humidity |
20-80% non-condensing |
|
| Storage |
-4-122°F / -20-50°C |
|
|
| |
| 2 years. First year Instacare Service. Lamp warranty is 1 year or 500 hours, whichever comes first. |
| |
- Microphone Input
- Automatic keystone correction
- Wireless LAN (Optional)
- USB Viewer
- 6000 hour Filter Life
- Auto power on
- ECO Mode technology
- Closed captioning
- Variable audio out
- Carbon savings meter
- Virtual Remote
- Sleep timer
- Quick power-off
- Built-in wall color correction
- Advanced AccuBlend
- AutoSense
- Wireless Image Utility
|
