MAXHUB 86 inch XBoard V7 Series Interactive Display – Model V8650

The MAXHUB 86 inch XBoard V7 Series Interactive Display – Model V8650 is a interactive flat panel available in the UAE from Procure.ae.

The MAXHUB 86 inch XBoard V7 Series Interactive Display (Model V8650 ) redefines collaborative workspaces and classrooms with its advanced interactive display technology . This cutting-edge 86 inch 4K touchscreen offers ultra-responsive multi-touch functionality, making presentations, brainstorming, and digital lessons more engaging than ever. The V8650 supports wireless screen sharing, seamless video conferencing , and integrated smart annotation tools for intuitive content creation and sharing. With its robust Android operating system , the MAXHUB V7 Series ensures smooth operation, swift.

It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.

Screen Size

86 inch

Resolution

3840 x 2160 (4K UHD)

Brightness

350 nits

Touch Technology

Infrared

Key features

Ultra-Large 86 Inch 4K Display

Expansive screen with stunning Ultra HD resolution for vibrant visuals.

Multi-Touch Technology

Supports up to 20 simultaneous touch points for seamless collaboration.

Wireless Screen Sharing

Effortlessly connect and share content from multiple devices.

Integrated Android OS

Fast and intuitive interface with access to a range of productivity apps.

Smart Annotation Tools

Real-time note-taking and drawing directly on the screen.

Video Conferencing Compatible

Built-in camera and microphones for high-quality virtual meetings.

Anti-Glare Glass

Ensures clear visibility in all lighting conditions.

Powerful Stereo Speakers

Delivers crisp, immersive audio for presentations and media.

Specifications

General
Key Features	Windows Ink, Direct annotation, Palm rejection, Sharp erase, Multi-input recognition, Auto framing, Speaker tracking, Intelligent audio fence
What's in the Box	Pens, Stands, Modulars

Display
Aspect Ratio	16:9
Backlight	Direct LED
Brightness	350 nits
Camera	3 × 50 MP (Panorama + Telephoto + Telephoto)
Color Depth	10-bit (1.07 billion colours)
Color Gamut	90% NTSC
Contrast Ratio	1,200:1
Panel Technology	IPS
Refresh Rate	60 Hz
Resolution	3840 x 2160 (4K UHD)
Response Time	8 ms
Screen Size	86 inch
Touch Accuracy	±0.5 mm
Touch Points	50-point multi-touch
Touch Response Time	≤2.5 ms
Touch Technology	Infrared
Viewing Angle	178° (H) / 178° (V)

Performance
Operating System	MAXHUB OS 7.0 powered by Windows

Audio
Audio In	Audio in × 1
Audio Out	Audio out × 1
Microphone	16-mic array, 15 m pickup range, 180° pickup
Pickup Range	15 m
Speaker Output	2 × 10 W + 20 W
Speaker Type	Built-in

Connectivity
Bluetooth	Bluetooth 5.2
Ethernet	RJ45 (Gigabit) × 2
HDMI Inputs	HDMI In × 2
HDMI Outputs	HDMI Out × 1
OPS Slot	Optional
Protocols	RS-232 / IP control; Crestron, Extron, Q-sys
Serial Port	RS-232 × 1
Touch USB Ports	Touch USB 2.0 × 1
USB Ports	USB 2.0 × 1, USB 3.0 × 2
USB-C Ports	USB-C In × 1
Wi-Fi	Wi-Fi 6 (802.11ax), 2.4/5 GHz

Physical
Duty Cycle	16/7
Surface Protection	Anti-glare smooth glass

Compliance
IP Rating	IP5X

QR code to MAXHUB 86 inch XBoard V7 Series Interactive Display – Model V8650 on procure.ae

Get our best price for this product

Scan to open it on procure.ae, or contact the Procure sales team:
☎ +971 4 546 5041 · WhatsApp · ✉ info@procure.ae · 🔗 View product page

This sheet is compiled from the product data held on procure.ae. For fully accurate and up-to-date figures, always refer to the manufacturer’s own specification sheet or datasheet for this model.

Specifications are provided by the manufacturer and may change without notice.

Pricing is quote-based. Contact Procure for current pricing and availability.

Delivery across the UAE and beyond, installation on request and manufacturer-backed warranty.
