Logitech LoRaWAN Gateway for Logitech Spot Sensors – 950-000124

The Logitech LoRaWAN Gateway for Logitech Spot (950-000124) connects Logitech Spot room sensors to the network, so hundreds of sensors can report across an office. It supports Wi-Fi 2.4 GHz and Ethernet backhaul, uses a 3 dBi swivel LoRa antenna and works only with Logitech Spot sensors. Procure.ae supplies it across the UAE.

The gateway receives LoRaWAN signals from Logitech Spot sensors through a swivel LoRa antenna rated at 3 dBi peak gain, connected by SMA or RP-SMA. Its receiver sensitivity is -141 dBm at SF12, and transmit power is configurable from 5 dBm to 27 dBm. Backhaul uses Wi-Fi 2.4 GHz or Ethernet (RJ45, 10/100 Mbps). The unit runs an ARM Cortex-A9 processor with 256 MB DDR RAM and 8 GB eMMC storage, and its casing is rated IP30. It is powered by a 230 V AC to 12 V DC adapter.

Use it in areas without a Logitech CollabOS device, such as Tap Scheduler or Rally Bar, to connect Spot sensors throughout an office. The gateway is configured through its USB Type-A port, and the manufacturer notes that firmware is required for configuration and management, available at hub.sync.logitech.com/logitech-spot. Security options include SecureBoot, SecureStorage, mTLS protection and SafeReboot. It mounts on a wall using two oblong holes or sits flat on a table on four domes. It works only with Logitech Spot sensors.
