HP ZBook Mobile Workstation 15 G3
- SKU: 15-G3
Actual Stock Can Be Confirmed After Placing the Order.
Specification System features Operating system Windows 10 Pro 64 – HP recommends Windows 10 Pro. 1 Windows 10 Home 64 1 Windows 7 Professional 64 1 Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro 64) 2 FreeDOS 2.0Red Hat® Enterprise... See More
Specification
System features
- Operating system
- Windows 10 Pro 64 – HP recommends Windows 10 Pro. 1
Windows 10 Home 64 1
Windows 7 Professional 64 1
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro 64) 2
FreeDOS 2.0
Red Hat® Enterprise Linux® 6 & 7 (web support only)
(No Linux preloaded. Customer is responsible to obtain their own distribution.)
- Processor family
- Intel® Xeon® processor
6th Generation Intel® Core™ i5 processor
6th Generation Intel® Core™ i7 processor 3
- Processor
- Intel® Xeon® E3-1545M v5 with Intel® Iris™ Pro Graphics P580 (2.9 GHz, up to 3.8 GHz with Intel Turbo Boost Technology, 8 MB L3 cache, 4 cores)
Intel® Xeon® E3-1505M v5 with Intel HD graphics P530 (2.80 GHz, up to 3.70 GHz with Intel Turbo Boost Technology, 8 MB cache, 4 cores)
Intel® Core™ i7-6820HQ with Intel HD graphics 530 (2.70 GHz, up to 3.60 GHz with Intel Turbo Boost Technology, 8 MB cache, 4 cores)
Intel® Core™ i7-6700HQ with Intel HD graphics 530 (2.60 GHz, up to 3.50 GHz with Intel Turbo Boost Technology, 6 MB cache, 4 cores)
Intel® Core™ i5-6440HQ with Intel HD graphics 530 (2.60 GHz, up to 3.50 GHz with Intel Turbo Boost Technology, 6 MB cache, 4 cores) 3
- Chipset
- Mobile Intel® CM236
- Environmental
- Low halogen 17
Memory
- Maximum memory
- 64 GB DDR4-2133 ECC SDRAM or 64 GB DDR4-2133 non-ECC SDRAM
(Transfer rates up to 2133 MT/s. Non-ECC memory only available with Intel® Core™ procesors. ECC memory only available with Intel® Xeon® processors. )
- Memory Slots
- 4 SODIMM
Storage
- Internal drive
- 500 GB SATA (7200 rpm) 5
1 TB SATA (5400 rpm) 5
500 GB SATA SED (7200 rpm) 5
500 GB SATA SED FIPS 140-2 (7200 rpm) 5
500 GB (8 GB cache) SATA SSHD 5
256 GB up to 512 GB M.2 SATA SED SSD 5
256 GB up to 1 TB HP Z Turbo Drive G2 (NVMe PCIe SSD) 5
Display and graphics
- Display
-
- 39.6 cm (15.6") diagonal FHD SVA anti-glare LED-backlit (1920 x 1080)
- 39.6 cm (15.6") diagonal FHD UWVA IPS anti-glare LED-backlit (1920 x 1080)
- 39.6 cm (15.6") diagonal FHD Touch UWVA IPS LED-backlit (1920 x 1080)
- 39.6 cm (15.6") diagonal UHD DreamColor UWVA IPS anti-glare + PSR LED-backlit (3840 X 2160)
- Graphics
- Integrated:
Intel® HD graphics 530
Intel® HD graphics P530
Intel® Iris™ Pro Graphics P580
Discrete:
NVIDIA® Quadro® M600M (2 GB dedicated GDDR5)
NVIDIA® Quadro® M2000M (4 GB dedicated GDDR5)
NVIDIA® Quadro® M1000M (2 GB dedicated GDDR5)
AMD FirePro™ W5170M (2 GB dedicated GDDR5) 9,18
(Intel® HD Graphics 530 integrated on Core™ i7 and Core™ i5 processors. Intel® HD Graphics P530 and Intel® Iris™ Pro Graphics P580 integrated on Xeon® processors.)
Expansion features
- Ports
- Left side:
1 RJ-45
1 VGA
1 USB 3.0 (charging)
Right side:
1 power connector
2 Thunderbolt™ 3
1 HDMI 1.4
3 USB 3.0
1 stereo microphone-in/headphone-out combo 6
- Expansion slots
- 1 SD UHS-II flash media
1 smart card reader
(SD supports next generation secure digital and is backward compatible to SDHC, SDXC)
- Audio
-
- Bang & Olufsen HD audio. Integrated stereo speakers and microphone (dual-microphone array when equipped with optional webcam). Button for volume mute, functions keys for volume up and down. Combo microphone-in/stereo headphone-out jack.
- Camera
- 720p HD webcam 10
- Keyboard
- HP Spill Resistant Keyboard (backlit with function key control)
- Pointing device
- Image sensor touchpad with on/off button, two-way scroll, gestures, three pick buttons. Pointstick with three additional pointstick buttons.
Communications
- Network interface
- Integrated Intel® I219-LM Gigabit Network Connection
Dimensions and weight
- Dimensions (W x D x H)
- 386 x 264 x 26 mm
- Weight
- Starting at 2.63 kg
(Weight varies by configuration and components)
Power and operating requirements
- Energy efficiency
- ENERGY STAR® certified and EPEAT® registered configurations available 16
- Power supply
-
- 150 W Slim Smart AC adapter (external)
- Battery type
-
- HP Long Life 9-cell 90 WHr Li-ion polymer
