HP ZBook Mobile Workstation

Specification

System features

Operating system

Windows 10 Pro 64 – HP recommends Windows 10 Pro. 1
Windows 10 Home 64 1
FreeDOS 2.0

Processor family

7th Generation Intel® Core™ i7 processor (i7-7500U, i7-7600U models)
7th Generation Intel® Core™ i5 processor (i5-7200U, i5-7300U models)

Processor

Intel® Core™ i7-7600U with Intel® HD Graphics 620 (2.8 GHz, up to 3.9 GHz with Intel® Turbo Boost Technology 2.0, 4 MB cache, 2 cores)
Intel® Core™ i7-7500U with Intel® HD Graphics 620 (2.7 GHz, up to 3.5 GHz with Intel® Turbo Boost Technology 2.0, 4 MB cache, 2 cores)
Intel® Core™ i5-7300U with Intel® HD Graphics 620 (2.6 GHz, up to 3.5 GHz with Intel® Turbo Boost Technology 2.0, 3 MB cache, 2 cores)
Intel® Core™ i5-7200U with Intel® HD Graphics 620 (2.5 GHz, up to 3.1 GHz with Intel® Turbo Boost Technology 2.0, 3 MB cache, 2 cores) 2,3

Chipset

Chipset is integrated with processor

Environmental

Low halogen 17

Memory

Maximum memory

32 GB DDR4-2133 non-ECC SDRAM
(Transfer rates up to 2133 MT/s )

Memory Slots

2 SODIMM

Storage

Internal drive

1 TB SATA (5400 rpm) 4
500 GB SATA (7200 rpm) 4
500 GB SATA SED (7200 rpm) 4
500 GB SATA SED FIPS 140-2 (7200 rpm) 4
500 GB (8 GB cache) SATA SSHD (5400 rpm) 4
256 GB M.2 SATA SED SSD 4
512 GB M.2 SATA SED FIPS SSD 4
256 GB HP Z Turbo Drive G2 (NVMe™ PCIe® TLC SSD) 4
512 GB HP Z Turbo Drive G2 (NVMe™ PCIe® TLC SED SSD) 4
256 GB up to 1 TB HP Z Turbo Drive G2 (NVMe™ PCIe® MLC SSD) 4

Display and graphics

Display

• 35.56 cm (14") diagonal HD SVA anti-glare (1366 x 768)
• 35.56 cm (14") diagonal FHD SVA anti-glare (1920 x 1080)
• 35.56 cm (14") diagonal FHD SVA anti-glare touch screen (1920 x 1080)
• 35.56 cm (14") diagonal FHD UWVA anti-glare (1920 x 1080)

Graphics

Integrated:
Intel® HD graphics 620
Discrete:
AMD FirePro™ W4190M (2 GB dedicated GDDR5) 7

Expansion features

Ports

Left side:
1 USB 3.0 (charging)
1 VGA
Right side:
1 DisplayPort 1.2
1 headphone/microphone combo
1 power connector
1 RJ-45
1 USB 3.0
1 USB 3.1 Gen 1

Expansion slots

1 Smart card reader
1 SD media reader
(SD supports next generation secure digital and is backward compatible to SDHC, SDXC)

Audio

• Bang & Olufsen HD audio. Integrated stereo speakers and microphone (dual-microphone array when equipped with optional webcam). Button for volume mute, functions keys for volume up and down. Combo microphone-in/stereo headphone-out jack.

Camera

720p HD webcam (optional) 9

Keyboard

HP Spill Resistant Keyboard (backlit with function key control)

Pointing device

Image sensor touchpad with on/off button, two-way scroll, gestures, two pick buttons. Pointstick with two additional pointstick buttons.

Communications

Network interface

Integrated Intel® I219-LM GbE for vPro™ processors
Integrated Intel® I219-V GbE for non-vPro™ processors

Dimensions and weight

Dimensions (W x D x H)

33.8 x 23.7 x 2.2 cm; 32.6 x 23.43 x 1.79 cm
(Height measurement taken at front of notebook.)

Weight

Starting at 1.64 kg
(Weight varies by configuration and components)
