HP LaserJet Pro M501n

Specification

Printing Specifications

Print speed black:

Normal: Up to 43 ppm 1

First page out (ready)

Black: As fast as 5.8 sec 2

Print quality black (best)

• 600 x 600 dpi, up to 4800 x 600 enhanced dpi

Print Resolution Technologies

HP FastRes 1200, HP ProRes 1200, 600 dpi

Duty cycle (monthly, A4)

Up to 100,000 pages 3

Recommended monthly page volume

1,500 to 6,000 4

Print technology

• Laser

Processor speed

1500 MHz

Print languages

HP PCL 5, HP PCL 6, HP Postscript Level 3 emulation, direct PDF (v 1.7) printing, URF, PCLM, PWG

Display

• 2-line LCD (text)

Replacement cartridges

HP 87A Black Original LaserJet Toner Cartridge (9,000 yield) CF287A, HP 87X Black Original LaserJet Toner Cartridge (18,000 yield) CF287X 11

Connectivity

HP ePrint capability

Yes

Mobile printing capability

HP ePrint
Apple AirPrint™
Mopria™-certified

Wireless capability

• No

Connectivity, standard

• Hi-Speed USB 2.0 Host/Device Ports
• Fast Ethernet 10 Base-T/100 Base-TX, Gigabit Ethernet 1000 Base-T

Network ready

Standard (built-in Gigabit Ethernet)

Minimum system requirements

• Compatible OS (see "Compatible Operating Systems")
• CD-ROM drive or Internet connection (for software installation)
• Dedicated USB connection or a network connection (wired or wireless)
• 1 GB available hard disk space
• For operating system minimum hardware requirements, see the OS manufacturer, such as microsoft.com

• Compatible OS (see "Compatible Operating Systems")
• Internet connection (for software installation)
• Dedicated USB connection or a network connection (wired or wireless)
• 1 GB available hard disk space
• For operating system minimum hardware requirements, see the OS manufacturer, such as Apple.com

Memory specifications

Memory

256 MB

Maximum memory

256 MB

Paper handling

Paper handling input, standard

• 100-sheet multipurpose tray and 550-sheet main cassette

Paper handling input, optional

Optional 550-sheet cassette tray (Tray 3) 14

Paper handling output, standard

• 250-sheet face down output tray

Maximum output capacity (sheets)

Up to 250 sheets

Duplex printing

• Manual

Media sizes supported

• Tray 1: 10 x 15 cm, A4, A5, A6, Envelope B5, Envelope C5, Custom, Envelope DL, B5 (JIS), B6 (JIS)
• Tray 2, Tray 3: A4, A5, A6, Custom, B5 (JIS), B6 (JIS)

Media sizes, custom

Tray 1: 76.2 x 127 mm to 215.9 x 355.6 mm; Tray 2, Tray 3: 105 x 148 mm to 215.9 x 355.6 mm

Media types

Paper (plain, light, midweight, intermediate, heavy, extra heavy, bond, cardstock, coloured, letterhead, preprinted, prepunched, recycled, rough, ecofficient); Envelopes; Labels; Transparencies

Supported media weight

Tray 1: 60 to 220 g/m²; Tray 2, Tray 3: 60 to 220 g/m²

Power and operating requirements

Power

Input voltage: 200 to 240 VAC, 50 Hz (Not dual voltage, power supply varies by part number with #option code identifier)

Power consumption

660 watts (active printing), 6.1 watts (ready), 1.3 (sleep), 0.7 watts (auto-off/wake on USB connection, disabled at shipment), 0.1 watts (auto-off/manual-on), 0.1 watts (manual-off) 7

Operating temperature range

15 to 32.5ºC

Operating humidity range

30 to 70% RH

Acoustic power emissions (ready)

4.0 B(A) 6

Acoustic pressure emissions bystander (active, printing)

54 dB(A) 6

Dimensions and weight

Minimum dimensions (W x D x H)

418 x 376 x 289 mm 5

Maximum dimensions (W x D x H)

418 x 639 x 289 mm 5

Weight

11.4 kg

Package dimensions (W x D x H)

497 x 398 x 466 mm

Package weight

14.5 kg
