HP EliteOne 800 G3 60.4 cm (23.8") Touch All-in-One PC

Specification

System features

Operating system

Windows 10 Pro 64 – HP recommends Windows 10 Pro. 1
Windows 10 Home 64 1
Windows 10 Home Single Language 64 1
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) 3
FreeDOS 2.0

Processor family

7th Generation Intel® Core™ i3 processor (i3-7100, i3-7300, i3-7320 models)
7th Generation Intel® Core™ i5 processor (i5-7500, i5-7600 models)
7th Generation Intel® Core™ i7 processor (i7-7700 model)
7th Generation Intel® Pentium® processor (G4560, G4600, G4620 models)
7th Generation Intel® Celeron® processor (G3930, G3950 models)
6th Generation Intel® Core™ i7 processor (i7-6700 model)
6th Generation Intel® Core™ i5 processor (i5-6600, i5-6500 models)
6th Generation Intel® Core™ i3 processor (i3-6100 model) 4,5

Processor

Intel® Core™ i7-7700 with Intel HD Graphics 630 (3.6 GHz, up to 4.2 GHz with Intel Turbo Boost, 8 MB cache, 4 cores)
Intel® Core™ i5-7500 with Intel HD Graphics 630 (3.4 GHz, up to 3.8 GHz with Intel Turbo Boost, 6 MB cache, 4 cores)
Intel® Core™ i5-7600 with Intel HD Graphics 630 (3.5 GHz, up to 4.1 GHz with Intel Turbo Boost, 6 MB cache, 4 cores)
Intel® Core™ i3-7100 with Intel HD Graphics 630 (3.9 GHz, 3 MB cache, 2 cores)
Intel® Core™ i3-7300 with Intel HD Graphics 630 (4 GHz, 4 MB cache, 2 cores)
Intel® Pentium® G4560 with Intel HD Graphics 610 (3.5 GHz, 3 MB cache, 2 cores)
Intel® Pentium® G4600 with Intel HD Graphics 630 (3.6 GHz, 3 MB cache, 2 cores)
Intel® Core™ i7-6700 with Intel HD Graphics 530 (3.4 GHz, up to 4.0 GHz with Intel Turbo Boost, 8 MB cache, 4 cores)
Intel® Core™ i5-6600 with Intel HD Graphics 530 (3.3 GHz, up to 3.9 GHz with Intel Turbo Boost, 6 MB cache, 4 cores)
Intel® Core™ i5-6500 with Intel HD Graphics 530 (3.2 GHz, up to 3.6 GHz with Intel Turbo Boost, 6 MB cache, 4 cores)
Intel® Core™ i3-6100 with Intel HD Graphics 530 (3.7 GHz, 3 MB cache, 2 cores) 4

Chipset

Intel® Q270

Form factor

All-in-one

Management features

Intel® vPro™ standard (Core i5 and Core i7)

Environmental

Low halogen 18

Memory

Maximum memory

32 GB DDR4-2400 SDRAM
(Transfer rates up to 2400 MT/s )

Memory Slots

2 SODIMM

Storage

Internal drive bays

One 6.35 cm (2.5")

External drive bays

One 9.5 mm slim

Internal drive

500 GB up to 1 TB 2.5" SATA (7200 rpm) 7
500 GB up to 1 TB SATA SSHD (5400 rpm) 7
256 GB up to 512 GB SATA SED 7
128 GB up to 1 TB HP Turbo Drive G2 TLC SSD (PCIe) 7
256 GB SATA SSD 7

Optical drive

Slim DVD-ROM
Slim DVD-Writer

Display and graphics

Display

• 60.45 cm (23.8") diagonal FHD IPS widescreen WLED-backlit anti-glare 10-point capacitive touch screen (1920 x 1080). Orientation designed to operate in portrait or landscape.

Graphics

Integrated:
Intel® HD Graphics 530
Intel® HD Graphics 630
Intel® HD Graphics 610 10,11,12
Discrete:

AMD Radeon™ RX 460 GFX (2 GB)(Models available with either integrated or discrete graphics except for Americas region (only discrete graphics model available).)

Webcam

Optional discrete dual microphone and optional integrated 2 MP webcam and IR sense (front) and 2 MP webcam (rear), maximum resolution of 1920 x 1080; Optional discrete dual microphone and optional integrated 2 MP webcam, maximum resolution of 1920 x 1080; Integrated webcam (optional)

Expansion features

Ports

Front:
Speakers (optional)
2 digital microphones
Back:
1 Dual-mode DisplayPort™
1 HDMI
4 USB 3.1 Type-A
1 power connector
1 RJ-45
1 audio line out
1 audio line in
1 security lock slot 8,20
Left Side:
1 headphone connector
1 universal audio jack with CTIA headset support
1 optical drive (optional)
Right side:
1 headphone connector
Right side:
2 USB 3.1 Type-A
1 SD 4 card reader (optional)
1 USB 3.1 Type-C™ 20,21

Expansion slots

1 M.2 internal connector for optional wireless NIC
2 M.2 internal connector for optional Turbo Drive G2 SSD

Media devices

Audio

Integrated Realtek ALC221 with combo microphone/headphone jack, line-in and line-out rear ports (3.5 mm), internal speaker.

Communications

Network interface

LANIntel® I219LM Gigabit Network Connection LOM
WLANIntel® 8265 802.11ac (2x2) wireless with Bluetooth® M.2 combo card vPro™
Intel® 8265 802.11ac (2x2) wireless with Bluetooth® M.2 combo card non-vPro™
Intel® 7265 802.11ac (2x2) wireless with Bluetooth® M.2 combo card non-vPro™ 9

Power and operating requirements

Energy efficiency

ENERGY STAR® certified and EPEAT® registered configurations available 17

Power supply

• 180 W, 87% efficient, active PFC

Dimensions and weight

Dimensions (W x D x H)

53.96 x 5.38 x 34.18 cm

Weight

6.03 kg
