Dinstar UC2000-VF-16G 16-Channel GSM VoIP Gateway

Dinstar UC2000-VF-16G 16-Channel GSM VoIP Gateway

The Dinstar UC2000-VF-16G is a 16-channel GSM VoIP gateway available from Procure.ae in the UAE, built for enterprises that route large volumes of mobile-to-VoIP calls.

The VF-16G scales GSM connectivity up to 16 hot-swappable SIM slots in one 1U chassis, with call-centre features such as SIP trunk groups, port groups, load balancing and automatic failover that keep traffic moving even when individual SIM lines drop out. Quad-band GSM coverage and a full HTTP API/SMPP toolset support both bulk SMS campaigns and application-driven messaging alongside voice.

It suits call centres, service providers and enterprises that need to route large volumes of mobile-to-VoIP traffic reliably, rather than occasional backup calling. The gateway integrates as a standard SIP trunk with 3CX, Yeastar and other SIP-based PBX platforms, and Procure.ae can arrange delivery and installation support across the UAE and GCC.

Type
GSM VoIP Gateway

Key features

01
16-channel GSM gateway with 16 hot-swappable SIM slots
02
Call-centre ready
SIP trunk groups, port groups, load balancing and failover
03
Quad-band GSM coverage across 850/900/1800/1900MHz
04
Bulk SMS and API tools
HTTP API, SMPP, SMS-to-email integration
05
Business software suite
white/black list, IVR customisation, balance checking
06
10,000-line local CDR storage for call logging and billing
07
1U rack-mount chassis for office or data-centre deployment

Specifications

General
Compatibility3CX, Yeastar and other SIP platforms
ModelUC2000-VF-16G
TypeGSM VoIP Gateway
Audio
Channels16 GSM
Connectivity
CellularGSM 850/900/1800/1900 MHz (quad-band)
ProtocolsSIP 2.0 (RFC3261)
Physical
MountingRack mount (1U)
Additional specifications
SIM slots16, hot-swappable
GSM bands850/900/1800/1900MHz (quad-band)
SIP complianceSIP v2.0 (RFC3261)
CDR storage10,000 local records
Form factor1U rack-mount chassis
