Dell Storage MD1280 Dense Enclosure
- SKU: MD1280
Actual Stock Can Be Confirmed After Placing the Order.
Specification Connectivity 6GB SAS Environmental Operating Conditions Temperature: Operating: 10° to 35°C (50° to 95°F) with maximum temperature gradation of 20°C per hour Non-operating: -40° to 65°C (-40° to 149°F) at a maximum altitude of 12,000 m (39,370ft)Relative humidity: Operating: 10% to 80% (non-condensing)... See More
Specification
Connectivity
- 6GB SAS
Environmental Operating Conditions
-
Temperature:
Operating: 10° to 35°C (50° to 95°F) with maximum temperature gradation of 20°C per hour
Non-operating: -40° to 65°C (-40° to 149°F) at a maximum altitude of 12,000 m (39,370ft)
Relative humidity:
Operating: 10% to 80% (non-condensing) with 29° C (82.4°F) maximum dewpoint.
Non-operating: 5% to 95% (non-condensing) with 33°C (91°F) maximum dewpoint.
Altitude:
Operating: -16 to 3048 m (-50 to10,000 ft)
Storage: -16 to 10,600 m (-50 to 35,000 ft)
Power
- Wattage: 2800 AC only
Input voltage range: 200-240 VAC
Frequency range: 50/60 Hz
Management
- Server dependent
Maximum Usable Capacity
- Up to 1.3PB when using 2 enclosures, maximum of 168 8TB HDDs
Storage
- Drive performance and capacity:
3.5" NL-SAS 6Gb HDD (7.2K): 4TB, 6TB
3.5" NL-SAS 4kn 6Gb HDD (7.2k): 6TB
3.5" NL-SAS 512e 6Gb HDD (7.2K): 8TB
Chassis
- 5U, 84 hot-pluggable 3.5" drive bays
Scalability
- Up to 672TB when using 84 x 8TB NL-SAS 3.5" HDDs
RAID Controllers
- 2 Enclosure Management Modules (EMM) provide redundant enclosure management capability
