DAG1000-4S Analog VoIP Gateway

The DAG1000-4S Analog VoIP Gateway is a voip & telephony available in the UAE from Procure.ae.

The DAG1000-4S Analog VoIP Gateway is a high-performance FXS VoIP gateway designed to connect analog telephones, fax machines, and legacy PBX systems to modern IP-based communication networks. It enables businesses to migrate to VoIP while preserving existing analog infrastructure.

It is supplied to corporate, education, and government organisations across the UAE, with procurement-ready quotations and regional delivery.

Type

Analog FXS VoIP Gateway

Weight

0.2 kg

Key features

FXS ports for analog phone and fax connectivity

SIP v2.0 compatibility with major VoIP platforms

High-quality voice with echo cancellation and noise suppression

Flexible dial plans and intelligent routing

Support for T.38 and pass-through fax

Web-based management, SNMP, and remote provisioning

Secure VoIP with firewall and encryption support

Scalable architecture for growing deployments

Specifications

General
Key Features	T.38 and pass-through fax (up to 14.4 kbps), Auto provisioning, Cloud-based management, SNMP v1/v2/v3, CDR
Type	Analog FXS VoIP Gateway

Performance
Storage Conditions	Temperature: -20 to 80 °C

Audio
Audio Codecs	G.711 A/μ, G.723.1, G.729 A/B, G.726, iLBC, AMR, Opus (optional)
Voice Quality	G.168 echo cancellation (128 ms), adaptive jitter buffer, VAD, silence suppression

Connectivity
Connectivity	4 x FXS (RJ11), WAN+LAN 10/100M RJ45, SIP
Ethernet	1 x WAN + 1 x LAN, 10/100 Mbps RJ45
Input Voltage	100-240 V AC, 50/60 Hz
Ports	4 x FXS (RJ11)
Protocols	SIP 2.0 (UDP/TCP), RFC3261, SIP over TLS, RTP/SRTP/RTCP, STUN, IPv4/IPv6, VLAN 802.1Q, TR069

Power
Power Consumption	5 W (typical)
Power Source	12 V DC, 1 A

Physical
Dimensions	242 x 152 x 40 mm
Operating Humidity	10% to 90% RH (non-condensing)
Operating Temperature	0°C to 45°C
Weight	0.2 kg

Compliance
Certifications	CE, FCC
