Smart Board 4K UHD Interactive LED Display with iQ, Brightness 360 cd/m², Contrast Ratio 5000 : 1, SBID-7286P
- SKU: SBID-7286P
Actual Stock Can Be Confirmed After Placing the Order.
SPECIFICATIONS Model: SBID-7286P Description SMART Board® 7086 Pro interactive display with iQ, one SMART Meeting Pro software room license and 10 SMART Meeting Pro software personal licenses. Dimensions & Weight Screen Size 86" (218.4cm) Diagonal Width 78 3/4" (200.1cm) Height 48 5/8" (123.5 cm)... See More
EMAIL
info@procure.ae
TELEPHONE
(+971) 454 65041
WHATSAPP
(+971) 454 65041
FREE SHIPPING
All orders over AED1999/-
SPECIFICATIONS
Model: SBID-7286P |
|
| Description | SMART Board® 7086 Pro interactive display with iQ, one SMART Meeting Pro software room license and 10 SMART Meeting Pro software personal licenses. |
| Dimensions & Weight | |
| Screen Size | 86" (218.4cm) Diagonal |
| Width | 78 3/4" (200.1cm) |
| Height | 48 5/8" (123.5 cm) |
| Depth | 5 5/8" (14.2 cm) |
| Weight | 205 lb. (91 kg) |
| Shipping dimensions (including pallet) | 86 1/2" x 60" x 14" (220 cm x 163 cm x 35.5 cm) |
| Shipping weight | 258 lb. (117 kg) |
| Note | All dimensions ± 1/8" (0.3 cm). All weights ± 2 lb. (0.9 kg). |
Interaction |
|
| Touch technology | HyPr Touch (Hybrid Precision Touch) proprietary hybrid system, which greatly improves upon its InGlass core by optimizing both touch and pen performance, resulting in virtually no lag and zero contact detect height |
| Multitouch capabilities | Up to 10 simultaneous touch, writing and erase points |
| Object Awareness | Behavior adjusts automatically to the tool or object you’re using, whether it’s a pen, finger, eraser or palm. |
| Pen ID | Four people can write independently and simultaneously, using different colored ink. |
Display |
|
| Type | LED |
| Aspect ratio | 16:9 |
| Optimal resolution | 3840 × 2160 at 60 Hz |
| Horizontal frequency (typical) | 135 kHz |
| Vertical frequency (typical) | 60 Hz |
| Contrast ratio (typical) | 5000:1 |
| Brightness (maximum) | 360 cd/m² |
| Pixel dimensions | 0.429 mm × 0.429 mm |
| Gamut | 72% of NTSC |
| Viewing angle | 178° |
| Response time (typical) | 8 ms |
| 1000BASE-T Ethernet | Two external ports for a four-port Gigabit Ethernet switched network connecting the interactive display and the iQ appliance to an external network and an external device, such as a computer |
| Presence detection | Dual sensors that reduce startup time and power consumption during inactivity |
| Audio | 10 W integrated speakers (×2) |
| Noise level | <30 dBA |
| Included cables and accessories | iQ appliance Country-specific power cable USB cable Pen (×4) Eraser |
iQ appliance |
|
| Wireless technology | Bluetooth 4.0 dual mode (backwards compatible with Bluetooth 2.1 + EDR) |
| Capture options | Establish a Bluetooth wireless connection with a supported mobile device (see below) by scanning the interactive display’s unique QR code |
| Capture options | Establish a Bluetooth wireless connection with a supported mobile device (see below) by scanning the interactive display’s unique QR code |
| Supported languages | French German Italian Japanese Korean Norwegian Simplified Chinese Spanish Swedish Traditional Chinese |
| Mounting holes | For a standard VESA 600 mm × 400 mm mounting plate Lower mounting holes 17 1/8" (43.4 cm) from the bottom of the interactive display |
| Mounting bracket depth | Minimum depth of 2" (5.1 cm) for all components on the back of the interactive display for airflow |
Connectors |
|
| Connector panel | OPS slot (for the iQ appliance) Stereo 3.5 mm out S/PDIF out VGA input connectors - VGA in - Stereo 3.5 mm in - USB Type-B HDMI 1 input connectors - HDMI 2.0 in - USB Type-B Display Port input connectors - DisplayPort in - USB Type-B USB Type-A2 RJ45 (×2) |
| Convenience panel | HDMI 2 input connectors - HDMI 1.4 in - USB Type-B USB Type-A (×2) |
| Bottom | AC power in AC power out RS-232 in RS-232 out |
| HDCP support | Version 1.4/2.2 |
Installation Requirements |
|
| Interactive display | See the SMART Board 7000 and 7000 Pro series interactive displays installation and maintenance guide (smarttech.com/kb/171164) |
SMART kapp app |
|
| Apple devices | iOS 9 or later operating system software 50 MB of storage iPhone 4S or later Third-generation iPad or later First-generation iPad mini or later Fifth-generation iPod touch or later |
| Android devices | Android 4.4.4 (KitKat) or later operating system 50 MB of storage (internal or SD card) 1024 MB of RAM 720p or better screen resolution Bluetooth 2.1 + EDR 3 megapixel or better rear-facing camera (recommended) |
SMART kapp viewer |
|
| Mobile | Safari for iOS 9 or later operating system software Chrome for Android 39.0.2171.93 or later |
| Desktop | Internet Explorer 10 or later Chrome 39.0.2171.95 or later Firefox 34.0.5 or later Safari 8.0 or later |
Room computers and guest laptops |
|
| 4K UHD | Graphics card that can support 3840 × 2160 resolution at 60 Hz and that has 1 GB DDR 5 memory |
Mini-computers |
|
| Dimensions | Smaller than 10" × 10" × 2" (25.4 cm × 25.4 cm × 5.1 cm) |
| Weight | Less than 10 lb. (4.5 kg) |
| Mounting | VESA 75 mm × 75 mm or 100 mm × 100 mm mounting pattern |
Cable Requirements |
|
| HDMI | Maximum length: 23' (7 m) Notes: Use only certified HDMI cables that have been tested to support the performance standard you require. The performance of cables longer than 23' (7 m) is highly dependent on the cable’s quality. |
| DisplayPort | DisplayPort 1.2 compliant or better Maximum length: 23' (7 m) |
| USB | Maximum length: 16' (5 m) |
| Important | Using cables that exceed these maximum lengths can produce unexpected results, such as degraded picture quality or USB connectivity. Refer to SMART installation standards (smarttech.com/kb/171035) for comprehensive information about cables and extensions for SMART hardware products. |
Storage and Operating Requirements |
|
| Power requirements | 100V to 240V AC, 50 Hz to 60 Hz |
Interactive display and iQ appliance power consumption at 77°F (25°C) |
|
| Standby mode | <2 W |
| Normal operating | 187 W |
| Maximum operating | 280 W |
Standalone interactive display power consumption at 77°F (25°C) |
|
| Standby mode | <2 W |
| Normal operating (out-of-box) | 172 W |
| Operating temperature | 41–95°F (5–35°C) |
| Storage temperature | -4–140°F (-20–60°C) |
| Humidity | 5–80% relative humidity, non-condensing |
Certification and Compliance |
|
| Regulatory certification | EU RED and LV Directives, ISED, cUL, FCC, UL, RCM, CITIC, TRA |
Environmental compliance |
|
| European Union | REACH, RoHS, WEEE, Battery and Packaging |
| U.S. | CONEG Packaging, California Prop 65 |
Optional accessories |
|
| WM-SBID-501 | Fixed wall mount for SMART Board interactive displays |
| Warranty | Three-year limited equipment warranty |
Extended warranty |
|
| EWY1-SBID-7286 | One-year warranty extension |
| EWY2-SBID-7286 | Two-year warranty extension |
No datasheet available.
